| US$32,500.00-35,000.00 | 1 Set (MOQ) |
| Genset Model | CCFJ350J |
| Power Factor | 0.8-3 phase |
| Frequency | 50HZ |
| Rated Current | 631A |
| Rated Voltage | 230V/400V |
| fuel pump mechanical controller | DC24V Electric starter or Air starter | air-cooled & water-cooled | |
| IP23 | H type insulation | Documents | |
| Common high pressure pipe | Dry type exhaust manifold | Sea water pump | |
| Colour:blue | Engine CCS ,alternator CCS | ||
| Local Engine Monitor and remote controller | |||
| Engine Model | X6170ZCD400-1 |
| Maker | WEICHAI |
| Rated power | 456kw |
| Rated speed | 1500rpm |
| Engine Type | Inline-6 Cylinders,4-stroke Diesel engine |
| Bore x Stroke | 160mm x 200mm |
| Combustion system | Direct Injection |
| Aspiration | Turbocharged & Intercooled |
| Cylinder Number | 6 |
| Cooling System | Heat Exchanger |
| Displacement | 24.12 |
| Rotation | Anti-clockwise (facing Flywheel) |
| Size of Flywheel Housing &Flywheel | SAE1#14 in |
| Emissions | IMO Tier II |
| Dry Weight | 3100kg |
| Dimension(L x W x H) | 2510 x 1245 x 1815mm |
| Alternator Maker | ShangHai Marathon |
| Alternator Model | MX-H-350-4 |
| Bearing Nos | 1 |
| Insulation Class | H |
| Steady-State Volt Adjustable Rate | ≤±2.5% |
| IP class | IP23 |
| Excitation Mode | Brushless |
| Rated Power Factor | 0.8 |
| Gen set Model | Length | Width | Height | Weight | ||||
| CCFJ350J-WI | 3466mm | 1236mm | 2001mm | 5363 | ||||
| The dimension and weight of the gensets in this selection guide are only for reference | ||||||||
