Stainless Oil Gauge Tape/Oil Sounding Tape/Oil Dipping Tape in China

Product Description

Stainless Oil Gauge Tape/Oil Sounding Tape/Oil Dipping Tape Description:
1.The oil sounding tape consists of handle, tape frame, crank, measuring tape, brass drawing weight, oil wiper, bracket and connector.
The scale direction of the tape faces the handle.
2.The locker utilizes a lock switch, a pin, and a spring to position the lock cylinder of the measuring rod. The oil wiper is suspended on the fixed pulley on the tape frame. The measuring tape passes through the felt of the oil wiper, and the oil attached during the measurement is used. Liquid scraping.
Application: Made of steel or stainless steel with a chromed brass drawing weight attached.
Metric or metric and inch graduated tapes are available.
The tapes are mounted to a stong frame with a wooden carrying handle.
Tapes of lengths up to 50 mtr are also available upon request.
Details is as following:

IMPA Code	Tape		Graduation
	Material	Size
650851	White Steel Tape	15m x 12.5mm	Metric
650852		20m x 12.5mm
650853		30m x 12.5mm
650856		15m/50ft x 12.5mm	Metric & Inch
650857		20m/66ft x 12.5mm
650858		30m/100ft x 12.5mm
650861	Black Steel Tape	15m x 12.5mm	Metric
650862		20m x 12.5mm
650863		30m x 12.5mm
650866		15m/50ft x 12.5mm	Metric & Inch
650867		20m/66ft x 12.5mm
650868		30m/100ft x 12.5mm
650871	Stainless Steel Tape	5m x 12.5mm	Metric
650872		10m x 12.5mm
650873		30m x 12.5mm
650876		15m/50ft x 12.5mm	Metric & Inch

---
