Laser Engraving and Cutting Equipment for Agricultural Machinery

Product Description

Laser Engraving and Cutting Equipment for Agricultural Machinery
PRODUCTION :
TECHNICAL PARAMETER :

Model	MAN-6090
Working area 6	600*900mm
Laser Type	Hermetic CO2 glass tube
Power supply	AC220/110, +-10%
Max moving speed	0-25000mm/Min
Worktable	honey comb/aluminium knife/(optional)
Locating precision	<0.01mm
Mini Shaping character	character:3x3mm, letter:2x2mm
Operating temperature	5-35 centigrade
Resolution ratio	≤4500DPI
Control configuration	DSP
Data transfer interface	USB(offline)
System environment	windows2000/XP/Vista/Win7/Win8/win10
Cooling way	water cooling and protection system
Graphic format supported	the files which CorelDraw, Photoshop, AutoCAD can identify(BMP, GIF,JPGE, PCX, TIFF,PLT, CDR.DMG etc.)
Compatible software	CorelDraw, AutoCAD
Cutting thickness	0-30mm(depends on different materials)
Color separation	up to 256 colors
Protection when water supply stops	yes
Net weight/ gross weight	200KG
Optional parts	high grade cooling system CW5000/double-head/rotary axis

DETAILS IMAGES :
Advantage :
1. Galvanized sheet lathe bed, moisture-proof against rust, solid and stable deformation.
2. Full acrylic cover, visual operations, simple and beautiful.
3. ABBA rail guide, with high precision, maintenance-free, low maintenance cost and long life.
4. DSP control system and USB interface. Software support Win XP, Win 7, compatible with ArtCut, CorelDraw, Photoshop, Auto CAD.
5. Front & rear entry for super-long plate to pass through.
6. Safety magnetic switch to make sure safety during work.
7. Imported linear rail guide with high durability, stability, precision.
8. Waste collect device, easy to pick up samples and save raw materials.
9. Most advanced double limit switches protect on XYZ axis, preventing the bump of laser parts.
SAMPLE SHOW :
Application :

Material	Engraving	Cutting		Material	Engraving	Cutting
Natural wood	√	√		Paper	√	√
Acrylic	√	√		Mylar	√	√
Glass	√	X		Pressboard	√	√
Double color plate	√	√		Rubber	√	√
Bamboo	√	X		Plywood	√	√
MDF	√	√		Fiberglass	√	√
Cloth	√	√		Painted metals	√	√
Leather	√	√		Plastic	√	√
Marble	√	X		Ceramic	√	X
Matte boards	√	√		Coated metals	√	X
Stone	√	X		Other materials	√	√

PACKAGING & SHIPPING :
Packages:
Firstly our worker will make sure your machine clean before package, then add Stretchy film for the whole machine and spare parts for sweet
protection, at last we will make export standard strong plywood case package according to your needs.
