| Tunnel size(mm) | 650(L)*505(W)mm |
| Conveyor Speed(m/s) | 0.22 |
| Conveyor height(mm) | 650 |
| Conveyor Max Load(kgs) | 160 |
| X ray dose per each inspection | Typical 2.0 μGy/h, guarantee 2.5 μGy/h |
| X ray leakage | Typical1.0 μGy/h, guarantee 1.5 μGy/h |
| Penetration | Typical 32mm, guarantee 30mm |
| Wire Resolution | Typical AWG40, guarantee AWG38 |
| Penetration Resolution | Typical AWG32, guarantee AWG30 |
| Spatial resolution: | Typical dia1.0mm,Vertical: dia1.0mm; Guarantee dia1.3mm,Vertical: dia1.3mm; |
| Power Consumption | 0.5KVA |
| Noise | | Film Safety | Guarantee ASA/ISO1600 Film |
| X-ray Sensor | L-Shaped Photodiode Array (multi-energetic) , 12bit Deep |
| Image Display | High resolution of 1024 * 1280 pixel; Image Grey Level: 4096 |
| Image Enhancement | 1-64times enlargement continuity, Color/BW, negative, high/low penetration, organic /inorganic Stripping, general enhancement, and pseudo color, etc. |
| Image Recall | All preceding images recallable, retrieval |
| Threat Image Projection | Inserting fictional, but realistic images of threat items into baggage during screening operation, for maintenance of vigilance, as well as training and assessment of image identification capability |
| Image Archive | Up to 200,000 images stored automatically, enable transferring to USB disk, and converting to JPG, BMP and other general formats |
| Miscellaneous Functions | Time/date display, counters, user management, system-on/X-ray-on timers, power on self test, built-in diagnostic facilities, dual-direction scanning, system log, system standby and stimulant training, ADS etc. |
| Network Applications | Multiple remote applications available based on Ethernet LAN and windows platform, such as image centralized storage and identify, recheck workstation, and network TIP, etc ( Optional) . |
| Images process | 24bit real time processing ,4colors analysis, Images displayed marked date and ID NO ,Count the number of bags |
| Operation temperature/Humidity | 0℃-45℃ / 5%-95%(non-condensing) |
| Storage Temperature/Humidity | -40℃to 70℃ / 5%-95%(non-condensing) |
| Operation Power | 220VAC(±10%) 50±3Hz (Optional: 100VAC,110VAC,120VAC,200VAC) |
| UPS | 15mins, 30mins, 60mins etc, optional |
