Mitutoyo Type 0-25mm Outside Micrometer Measuring Device

Product Description

Quick Detail:
1. Painted and fine cast frame.
2. Laser-etched scale for clear and easy reading.
3. Carbide measuring faces provide accuracy and wear resistance.
4. Ratchet thimble for precise application of force.
5. Supplied in fitted case.
Description:
This is one most standard mechanical outside micrometer, it is also called micrometer screw gauge,
external micrometer, used in engineering and physics to measure small distances with high accuracy.
The hardened and ground spindle along with a carbide anvil ensure durability and accuracy.
It also has the ratchet thimble allows precise application of pressure on the object being measured.
We supply a full measuring ranges from 0-25mm to 275-300mm, with graduation 0.01mm.
For ranges larger than 25mm, supplied with a setting standard for calibration.
All our outside micrometers come with fitted safe case packing and spanner.We also have set of
micrometers to meet customer's multiple measurement.
KM micrometers are of the finest quality available, at prices that competitive.
Specification:
Metric:

Order No.	Measuring Range	Accuracy	Graduation
KM-2106-25	0~25mm	±0.004mm	0.01mm
KM-2106-50	25~50mm	±0.004mm	0.01mm
KM-2106-75	50~75mm	±0.005mm	0.01mm
KM-2106-100	75~100mm	±0.005mm	0.01mm
KM-2106-125	100~125mm	±0.006mm	0.01mm
KM-2106-150	125~150mm	±0.006mm	0.01mm
KM-2106-175	150~175mm	±0.007mm	0.01mm
KM-2106-200	175~200mm	±0.007mm	0.01mm
KM-2106-225	200~225mm	±0.008mm	0.01mm
KM-2106-250	225~250mm	±0.008mm	0.01mm
KM-2106-275	250~275mm	±0.009mm	0.01mm
KM-2106-300	275~300mm	±0.009mm	0.01mm

Inch:

Order No.	Measuring Range	Accuracy	Graduation
KM-2106-1	0-1″	±0.00016″	0.0001″
KM-2106-2	1-2″	±0.00016″	0.0001″
KM-2106-3	2-3″	±0.0002″	0.0001″
KM-2106-4	3-4″	±0.0002″	0.0001″
KM-2106-5	4-5″	±0.00024″	0.0001″
KM-2106-6	5-6″	±0.00024″	0.0001″
KM-2106-7	6-7″	±0.00028″	0.0001″
KM-2106-8	7-8″	±0.00028″	0.0001″
KM-2106-9	8-9″	±0.00032″	0.0001″
KM-2106-10	9-10″	±0.00032″	0.0001″
KM-2106-11	10-11″	±0.00036″	0.0001″
KM-2106-12	11-12″	±0.00036″	0.0001″

Precautions:
1. Before measuring, clean measuring faces of the anvils and the spindle with soft cloth or soft paper,
then bring them together carefully by turning the ratchet stop.
2. After measuring, separate the anvil and tighten the fixing screws to avoid rust caused by prolonged contact.
3. Micrometers should not be stored in humid places with large temperature changes.
4. Do not use micrometer to measure moving or hot objects or to strike something.
Applications:
Outside micrometers are particularly useful in fields where precise measurements
are essential, such as engineering, machining, physics, and manufacturing.
In the manufacturing industry, the outside micrometer is often used to measure parts and components
to ensure the accuracy and quality of the product.
In the field of machining, it is often used for outer diameter machining, dimensional measurement
and roundness measurement to meet the needs of precision machining.
At the same time, the outside micrometer is also widely used in the automobile maintenance industry,
for example, to measure the diameter of tires, etc., to ensure the accuracy and safety of maintenance work.
1) Who are we?
Deko Corporation mainly dedicate to the development, manufacture and marketing of KM brand
precision measuring tools in China mainland.
2) What products do we carry?
Dial indicators, micrometers, calipers, bore gauges, height gauges,
dial thickness gauges, depth gauges, bevel protractors, gauge, blocks,level,etc.
3) What are the terms of trade?
We support FOB, C&F, CIF, EXW.
4) What are the forms of payment?
We accept T/T, L/C, D/A, D/P, Paypal, Western Union.
5) Do we accept customization?
Yes, OEM is available.
6) How about after-sales service?
One year warranty for all kinds of products.
If you find any defective accessories when receive goods, we will ship you news parts or
new product to replace. As an experienced manufacturer, we have very strict calibration
and inspection team, you can rest assured of our product quality.

---
