No. | unit | Tehnical parameters |
Model |
| 2V98FA |
Type |
| 2 cylinders V, air-cooled, 4 stroke, direct injector |
Bore | mm | 98 |
Stroke | mm | 88 |
Displacement | L | 1.326 |
Rated power | KW | 20 |
Rated speed | r/min | 3000 |
Fuel consumption | g/kw.h | 260 |
Output shaft rotation direction |
| Counterclockwise |
Lubrication method |
| Pressure splash |
Start mode |
| Electric |
Cooling mode |
| forced air-cooled |
Oil tank capacity | L | 4 |
Middle height | mm | 200 |
Size | mm | 570x580x660 |
Net weight | kg | 90 |
Injection pressure | Mpa | 19 |
Fuel supply advance angle (top line) |
| 21±1° |
Valve clearance | mm | Intake valve 0.1,Exhaust valve0.15 |
