Hot Selling Bench Lathe Turning Center 1440K Gear Head Lathe

Product Description

Product Description
Induction hardened,precision ground V-way bed
Dl-4 spindle is supported by high quality tapered roller bearing
12 steps of spindle speeds are available
High precision directly mounting chuck
Gap bed section provides for larger diameter work
Gearbox has large feed and threading functions
Carriage mounted spindle control lever
Adjustable gibs for slideways
Automatic feed and threading are fully interlocked
Tailstock may be offset for turning tapers
Super width bedway
Equipped with emergency stop button Product Parameters

Basic Info.
Model NO.		1440K Gear Head Lathe
Controlling Mode		Artificial
Setting	Mode	Floor-type
Certification		CE,ISO 9001
Specification		1990x760x1450mm
Origin		China
Power Source	Electric
Automatic Grade	Manual
Precision	High Precision
Condition	New
Trademark	JSC FICOM
Production Capacity	100 Sets/Year

TECHNICAL PARAMETERS
Model No.	Unit	1440K/1460K
distance between centers	mm mm mm	1000/1500 356 508
swing over bed
swing over gap
swing over cross slide	mm	210
taper of spindle bore		MT5
spindle nose spindle bore	mm	D1-4 40
step of spindle speeds	steps	12
range of spindle speeds	rpm	40-1800
range of cross feeds	mm/r	0.024-0.359
range of longitudinal feeds	mm/r	0.043-0.653
range of inch threads		4-56T.P.I
range of metric threads top slide travel	mm mm	0.4-7
		92
cross slide travel	mm	185
carriage travel travel of tailstorck quill taper of tailstock quill motor	mm mm W	945
		120
		MT3
		2400
packing size	mm kg	1990/2490x760x1450 996/1100
N.W.

Standard Accessories

3 jaws & 4 jaws chuck
(1440G: 160/200mm) (1440GB: 200/200mm) (1640G: 200/200mm)
Face plate (1440G/1440GB: 250mm) (1640G: 320mm)
Steady/follow rest	Iron casting stand(1440G)
Halogen work lamp	Coolant system
Foot brake	Toolbox & tools
Micro carriage stop	One piece casting stand(1440K)

Optional Accessories

Quick change tool post	Turning tools	Taper turning attachment
Collet attachment	Leadscrew cover	Digital readout
Chuck cover(1440G/1640G)

Company Profile
Certifications
Exhibition
Packaging & Shipping
FAQ
FAQs
Q1: How is the warranty?
A1: Warranty time is 15 months after BL date.
Q2: Can we visit your factory before order?
A2: Sure. All new and old friends are welcomed to visit us at our factory. Besides, we can pick up you at the station or airport if needed. We will be very honored to help with tickets and accommodation booking.
Q3: Do you have a stock?
A3: We have stock for popular models, we produce according to order.
Q4: What's the MOQ?
A4: One set only.
Q5: How about your quality?
A5: We have approved the ISO9001:2008 Quality management system.ISO14001 Environmental management system, OHSAS18001 International occupational health and safety management system, and Social Accountability 8000(SA8000). Most products have been approved by the European and American safety standards, including CE, GS, EMS&UL,90% of our products are exported to more than 40 countries and regions around the world, especially to Europe and America market and always win high reputation. So you can rest assured of our quality products and our best services.
Q6: Do you have professional engineers?
A6: Yes, we have professional engineers and designers. We can provide OEM services under Alpha brand.
Q7: Can you provide customized machines?
A7: Yes, we can design and manufacture according to your specific requirements.

---
