Compact Infrared Thermal Imaging Telescope with Enhanced Sensitivity

Product Description

Model	UTx318MR
Detector Type	Uncooled Vanadium Oxide
Video Format	MP4
Infrared Resolution	400×300
Photo & Video	Infrared Response Wavelength: 8-14μm
Multimedia Browsing	-
Pixel Size	12um
Motion Detection (Standby)	-
Frame Rate	50Hz
Electronic Compass	-
Thermal Sensitivity (NETD)	<25mk
Probabilistic Ranging	-
Focus Adjustment	Manual Focus
Hot Spot Tracking	-
Lens Focal Length	18mm
Picture-in-Picture	-
Aperture	F1.0
Mobile APP	iOS, Android
FOV (Field of View)	14.6°×11°
WiFi	Supports APP Screen Casting
Digital Zoom	1x, 2x, 4x, 8x Smooth Zoom
Eyepiece	Monocular Display, Diopter Adjustment: -5~+3
Color Palette	Iron Red, Rainbow, Red Hot, Black Hot, White Hot
Brightness Adjustment	5 Levels
Correction Mode	Background Correction, Shutter Correction, Automatic Correction
Contrast Adjustment	5 Levels
Display Screen	0.39" OLED
Language	Simplified Chinese, English
Display Resolution	1024x768
Battery Type	3250mAh Removable & Rechargeable Lithium Battery (UT-M21)
Focus Adjustment (Again)	Manual Focus
Auto Power Off	OFF/5min/15min/50min, Default OFF
Laser Pointer	Yes (Wavelength: 650nm)
Operating Time	>3 Hours
Laser Rangefinder	Yes (Wavelength: 900-908nm)
Battery Life	≤3 Hours
Measurement Range	10-1200m
Charging Voltage/Current	5V/2A
Measurement Accuracy	±1m (10-100m), ±(1+L*0.25%) m (L is target distance)
Operating Temperature	-10°C50°C (32°F122°F)
Storage	Internal Storage, 16GB
Storage Temperature	-20°C60°C (-4°F140°F) <85%RH (Non-condensing)
Data Interface	Type-C Interface, Supports Charging, Data Access, Video Output
Protection Grade	IP67, Resistant to 2m Drop
Image Format	PNG
Certifications	UL Battery Certification, RoHS Certification, CE Certification

Model	UTx635M
Detector Type	Uncooled Vanadium Oxide Microbolometer
Infrared Resolution	640x480
Multimedia Browsing	Supported
Infrared Response Wavelength	8-14μm
Motion Detection (Standby Mode)	Supported
Pixel Size	17μm
Frame Rate	50Hz (PAL) / 60Hz (NTSC) (Selectable)
Probabilistic Ranging	Supported
Thermal Sensitivity (NETD)	≤30mK @ 30°C
Hot Spot Tracking	Supported
Focus Adjustment	Manual Focus
Lens Focal Length	19mm
Mobile APP	iOS/Android Supported
Aperture	F1.0
FOV (Horizontal x Vertical)	24.4° x 18.3°
Battery Capacity	5000mAh (Built-in, Rechargeable)
Charging Time	About 4 Hours
Operating Temperature	-10°C to 50°C
Storage Temperature	-20°C to 60°C
Wi-Fi	Supported (For APP Screen Casting)
Display	3.5" IPS LCD Display (640x480 Resolution)
Digital Zoom	1x, 2x, 4x, 8x
Eyepiece	Monocular Display, Diopter Adjustment (-5D to +3D)
Color Palettes	Ironbow, Rainbow, White Hot, Black Hot, etc.
Image Format	JPEG
Video Format	MP4
Video Recording	Supported
Interface	USB Type-C (For Charging, Data Transfer, Video Output)
Protection Grade	IP66 (Dust-tight and Protected against Powerful Water Jets)
Drop Resistance	Resistant to Drops from 1.5m
Certifications	CE, RoHS, FCC
