Wortai Highly Reliable and Quality Automatic Range Switching Digital Clamp Multimeter 2000A

Product Description

Production Description

The WT6050-2000A is a 3 3/4-digit digital clamp meter with automatic range switching. It is a highly reliable digital clamp multimeter driven by batteries and has stable performance. The instrument adopts a 15mm character height LCD display, providing clear readings. It features automatic/manual range selection, data hold, frequency duty cycle measurement and an auto power-off function. The display is intuitive, making it more convenient to use.
This series of clamp meters can be used to measure parameters such as DC voltage, AC voltage, AC current, DC current (model WT6050-2000A), resistance, capacitance, frequency, diode testing and continuity testing. With the dual-integral A/D conversion of large-scale integrated circuits as the core, it has the function of automatic range switching and is an excellent tool instrument, an ideal choice for laboratories, factories, radio enthusiasts and households.

Product Paramenters

Basic Function	Range	Accuracy
		WT6050-2000A
DC Voltage	400mV/4V/40V/400V	±(0.5%+4d)
	1000V	±(1.0%+6d)
DC Current	400A	±(2.5%+20d)
	2000A	±(3.5%+20d)
AC Voltage	400mV	±(1.6%+8d)
	4V/40V/400V	±(0.8%+10d)
	750V	±(1.0%+10d)
AC Current	400A	±(2.5%+20d)
	2000A	±(3%+10d)
Resistance	400Ω	±(0.8%+5d)
	4kΩ/40kΩ/400kΩ/4MΩ	±(0.8%+4d)
	40MΩ	±(1.2%+10d)
Capacitance	40nF	±(5.0%+30d)
	400nF/4μF/40μF	±(3.5%+8d)
	100μF	±(5.0%+10d)
Frequency	5.120Hz/51.20Hz/512.0Hz/5.120kHz/51.20kHz/512.0kHz/100.0kHz	±(0.5%+4d)
Special function		WT6050-2000A
Diode test		√
Continuity buzzer		√
Low battery indication		√
Auto power off		√
Hold		Data hold/Peak value hold
Relative value measurement		√
Duty cycle measurement		0.1%-99.9%
AC Frequency response		40~400Hz
Sampling rate		3 times/s
Operation way		Manual range
Max.Display		3999
Clamp size		55mm
Power		9V/6F22

Test and Inspection Equipments

Packing and Delivery

Certifications

WORTAI Album

Why Choose WORTAI

* More than 20 years manufacturing experience in electric power industry* Top quality products, ISO9001, ISO14001, KEMA, CNAS certificates* Custom tailored products, OEM & ODM are welcome* Challenging prices for giving customers the greatest benefits* Fast response time, we promise to reply customer's email within 24 hours* Attractive lead times, plenty of equipments and workers to ensure the delivery on time* Top skilled technicians* Flexibility WORTAI have been sold to over 20 countries and regions, spread all over Asia, Africa, Middle & South America, Middle East and Europe, we also has done OEM service for some world famous brands.Choosing WORTAI means being one step ahead of the general development. We look forward to a closer relationship and mutually beneficial cooperation with any prospective customers in the near future. WORTAI will work with you shoulder-to-shoulder to satisfy your needs.With competitive price, good quality and best service, WORTAI will be your most wise choice. Together we're winners! Let's do it right now!

---
