| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
| PARAMETERS | MQ-6025A | |
| Swing dia.of workpiece | 250mm | |
| Distance between centers | 700mm | |
| size of working area | 940*135mm | |
| Longitudinal travel of table | 480mm | |
| Swing angle of table | 120°(60°) | |
| Max travel of wheel head cross vertical | 225mm | |
| Wheel center line of the min distance between the top | 50mm | |
| Wheel center line of the max distance between the top | 265mm | |
| The max movement in the vertical direction | 270mm | |
| Wheel center line up to the top | 200mm | |
| Wheel center line down to the top | 65mm | |
| Swing angle of wheel head in horizontal pline | 360° | |
| Swing angle of wheel head in vertical pline | 30°(±15°) | |
| The end taper of the spindle | MT3# TAPER ANGLE | |
| Grinding head motor power 50Hz | Power | 0.85/1.1KW |
| Speed | 1400/2800rpm | |
| The speed of grinding head | 3010/6010rpm | |
| The Motor of Cylindrical grinding attachment:50Hz | Power | 0.25KW |
| Speed | 1400RPM | |
| The size of the machine | 1650*1150*1500mm | |
| The weight of the machine | 940kg | |
