Horizontal Spice Food Flour Powder Mixer Machine

Product Description

Horizontal spice food flour powder mixer machine
General Introduction:
1. The major sections of a mixer are barrel, ribbon agitators, feeding ports, discharging port and driven unit.
2. Double ribbon mixer drive the material from two ends to centre through the help of the outer ribbon, while the inner ribbon push the material from centre to two ends. thus material achieve a high mixing effect at short time.
3. Our ribbon mixer can be equipped with heating or cooling jacket if temperature control is required.
4. All of our powder mixer can tolerate about 10% liquid additives. We will add spraying or atomizing unit inside the tank.
Major Parameters For Technology Selection:
1. powders name and character (mesh and density)
2. output per batch
3. stainless 304/316L or carbon steel
4. the electrical environment in machine's using place
Technical information:

Model	Capacity	Motor	Weight	Dimension
WSX-15(SS)	15 kg/8min	1.5 kw	70 kg	950*400*940mm
WSX-25(SS)	25 kg/8min	2.2 kw	85 kg	800*650*1200mm
WSX-80( Carton steel)	80 kg/8min	4 kw	130 kg	900*850*1200mm
WSX-350(Carton steel)	350 kg/8min	5.5 kw	490 kg	1200*1100*1400mm

Different customized cases:
1. Agglomerated material larger than 5mm is contained in the raw material
2. Bulk density of the raw material bigger than 3kg/l
3. Materials are easy to get damp and not allowed to be exposed to the atmosphere, the mixer need to be vacuum or negative pressure
4. Fill compressed air to the mixer barrel, and keep the pressure
5. Materials with a large friction coefficient, mixer need to do a special Wear-resistant surface treatment.
6. Material is not allowed to contact with the metal surface during mixing process
7. Mixer need to be heated up to 200 Celsius degree
8. Heavy duty (loading material into mixer before turning on it) is required.

---
