VMC 850 CNC Milling Machine Vertical Machining Center

Product Description

Features
VMC850 is designed for machining complicated mold profile, automotive parts, and housing parts. It has distinguished advantage in machining mold, especially the small size mold. It has big torque output at low speed range, which is suitable for high strength steel and high temperature alloy steel which are difficult for machining.
Suitable to machine large machinery parts, automative part, mold etd;
With Taiwan high speed spindle to 10000rpm;
High accuracy; High speed; High rigidity; Low noise

Specification	Unit	VMC850
Table size	mm	1000*500
Max table load	Kg	500
Table travel X	mm	800
Table travel Y	mm	550
Table travel Z	mm	550
Spindle nose to table surface	mm	150-650
Spindle center to column surface	mm	575
Spindle speed range and driving method	rpm	8000 belt driving
Spindle taper	/	BT40
Spindle diameter	mm	150
Max tool diameter(No adjacent tool)	mm	φ80(φ130)
Max tool length	mm	300
Max tool weight	kg	8
Tool selection		random
Shank	Type	BT-40
Magazine capacity	T	24
Tool exchange mode		Arm type
Tool change time	Sec	3
Rivet	type	P40-1(45°)
Controller		Siemens

FAQ
1. MOQ
1 set
2. DELIVERY TIME
It depends on the machine and model you choose. Mostly 2 months - 4months. All machines are 100% new and not used.
3. PAYMENT TERM
T/T 30% down payment when order, 70% balance payment before shipment.
4. WARRANTY PERIOD
13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely, the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.

---
