| US$200.00-60,000.00 | 1 Piece (MOQ) |
| Pattern | SBW | DBW |
| Phase | 3Ph | 1Ph |
| Specification | 10KVA~3000KVA | 3KVA~500KVA |
| Input Voltage | 304V~456V | 176V~264V |
| Output Voltage | 380V±1-5% / can be set | 220V±1-5% / can be set |
| Stabilization Time | 1-5% / be able to adjust | |
| Voltage Accuracy | Setting time is less than 1.5s when the input voltage compares with the rated voltage changes within 10%. | |
| Ambient Temperature | -10ºC~+45ºC, the highest monthly average temperature should not exceed 35ºC. | |
| Working status | Fully automatic,long-term operation, arbitrary switching of mains/stabilizing voltage. | |
| Display Method | The current and voltage adopt LCD large screen display, man-machine dialogue interface, and abnormal status indicator display. | |
| Over and under voltage protection | When the input voltage exceeds the voltage regulator's over-voltage or under-voltage value, the equipment will automatically protect the no-voltage output. |
| Over current protection | When the current exceeds the rated value, the input is automatically cut off. |
| Overload, short circuit protection | When the load exceeds the specified overload capacity or short circuit of the equipment, the power supply can be automatically cut off within the specified time. |
| Limit protection | When the brush operation exceeds the area, the adjustment is automatically terminated. |
| Mains bypass function | When the voltage stabilizer needs maintenance or malfunctions, the manual switch can be switched to supply power in a direct connection state. |
| True effective sampling circuit control | High accuracy, good sensitivity, good measurement rate and frequency characteristics, high input impedance, low output impedance, wide power supply range and low power consumption. |
| Back to middle function | When the sampling voltage is lower than the lower limit reference voltage or higher than the upper limit reference voltage, the brush will automatically return to the center. |
