Max Spindle Speed
| rpm
| 3500（4000 max)
|
Finish after machining
|
| 1.6Ra
|
Spindle hole
| mm
| 25
|
Repeat positioning accuracy
| mm
| ±0.01
|
Unilateral cutting amount
| mm
| 2mm (3mm max)
|
Spindle Power
| kw
| 3.7Kw
|
X/Z Axis Motor
|
| 1Kw Servo
|
X Axis Travel
| mm
| 500
|
Z Axis Travel
| mm
| 180
|
Fast feed rate
| m/min
| 20m/min (30m/min max)
|
Clamping Diameter
| mm
| Hydraumaticφ40mm (φ50 max)
|
Cutting Feed Rate
| mm/rev
| 0.001-500
|
Cutting Length
| mm
| 180
|
Cutting Length With Lathe Center Frame
| mm
| 120
|
Machine Bed Inclination
| °
| 30
|
Controller
| KY
| KY980
|
Ball Screw
|
| Taiwan P4
|
Linear Guide
|
| Taiwan P4 Linear Guide rail
|
Weight
| kg
| 1800-2200
|
Machine Size
| Mm
| 1400*1200*1800
|
