High Speed Thickness Gauge with CE Approved

Product Description

Product Description
The PW-TCK-T02 thickness gauge adopts a mechanical contact measurement method. The design of the whole machine strictly meets the requirements of the standard. It is professionally suitable for accurate measurement of the thickness of various materials such as plastic film, sheets, diaphragms, foil, silicon wafers, paper, etc.

Features
1. The contact area and measurement pressure are designed in strict accordance with the standard, and various non-standard customizations are supported;
2. Using high-precision thickness measurement sensors, effectively guarantee the accuracy and repeatability of the measurement data;
3. The measuring head is automatically raised and lowered, effectively avoiding system errors caused by human factors;
4. It supports manual and automatic modes, which is convenient for users to use;
5. The standard micro printer can realize real-time historical data printing function;
6. Standard gauge block is standard, which is convenient for users to calibrate the sensor and better guarantee the accuracy of measurement data;
7. The key components are imported from world-renowned brands to ensure the accuracy and stability of the system;
8. Imported high-speed and high-precision sampling chip to ensure the real-time and accuracy of test data;
9. 7-inch high-definition color LCD screen, convenient for users to control and display real-time data and curves;
10. Support historical data for quick viewing and report printing.

Product Parameters

Index	Parameter
Range	0~2mm (standard); 0~6mm, 0~12mm (optional)
Resolution	0.1um
Repeatability	0.3um
Test speed	1~25 times/min
Measuring pressure	17.5±1 KPa (film); 50±1 KPa (paper)
Contact area	50 mm2 (film); 200 mm2 (paper) Note: Choose one of film and paper; non-standard can be customized
Power supply	AC 220V 50Hz / AC 120V 60 Hz
Dimensions	320mm (L)×400 mm (W)×420 mm (H)
Approximate net weight	33kg

Company Profile
Company Introduction:
PW (Guangdong) Instruments Co., Ltd. was established in March 2007, a national high-tech enterprise, located in Room 901, Building 11, No. 2 Houjie Dongye Road, Houjie Town, Dongguan City, Guangdong Province, China. Through years of operation, the company has gathered a group of talents with considerable qualifications in the industry and has accumulated a large number of high-quality customers. In order to better serve customers in East China, the company established PW Instruments (Shanghai) Co., Ltd. in Shanghai and set up an instrument exhibition hall and testing center in Suzhou Industrial Park.
Corporate Culture:
Vision: Become a world-renowned instrument manufacturer
Mission: Provide customers with high-quality testing equipment
Values: Customer satisfaction is our aim.
Certifications

FAQ
Q: Are your company a trading one or a factory?A: Factory, More than 15 years focusing on test equipment field, 10 years exporting experience.Q: After an order is placed, when to deliver?A: Generally about 10-25 days, If we have inventory, we can arrange shipment within 3 days.Please be aware that our production lead times depend on specific items and item quantities.Q: What about the warranty with after-sales services?A: The testing machine is guaranteed for 12 months by PW, we can help you to repair your problem controller freely, even it's not from our factory. After the warranty, the professional after-sale service team will provide perfect technical support and help guests solve problems encountered while using our product, handle guest problems and complaints in a professional and timely.Q: What about the product's services and quality?A: Each piece of equipment must be carried out 100% quality examination and test when shipping and delivering goods. Product use training, each of our products provides video training to show you how to install & operate. We can arrange engineer to train the operation of equipment to customer's company when you need. products are widely recognized and trusted by users.A: Considerate Service Different countries plugs, manually change the voltage from 110V to 220V, insurance indicator.Q: Can your products be customized?A: Yes, our product can be customized according to your parameters.

---
