| US$250,000.00-350,000.00 | 1 SET (MOQ) |
| Technical Parameters | |
| Model | CH RSMSUS-G |
| Working width | 213",245",260" |
| Gauge | E6/E9/E10/E12/E18 |
| Bars | 2 GB and one bar for filler threads |
| Pattern drive | Pattern disks |
| Warp plain stitch structure | GB1:1-2//1-2 |
| Pillar stitch structure | GB2: 1-0//0-1 |
| Circle disk | GB3: 0-0// |
| Let-off way and take-up | EBC and Electronic take-up |
| Power of Main Motor | 35kVA |
| Control type of Main Motor | Inverter Control |
| Working Speed | 500-1300 RPM |
| Language - Operator Interface | Chinese- English |
| Voltage | 380V |
| Main configuration | |
| Main Motor | Siemens OF Germany |
| Inverter | Mitsubishi of Japan |
| Servo motor | Mitsubishi of Japan |
| Bearings | SKF and INA of Germany |
| All needles on the machine | GROZ BECKERT |
| Needle bars/Core needle bars/Stitch comb bars/Comb bars materials | Aluminium Magnesium Alloy |
| Test components | AUTONICS OF SOUTH Korea and KOYO OF Japan |
| Touch screen | MCGS OF China |
| Operating components | France |
| Terminal components | PHOENIXCONTACT OF Germany |
| All machined parts | Manufactured by Tianyi company themselves based karlamyer experience. |
