| US$60,000.00-80,000.00 | 1 Piece (MOQ) |
| SR.NO | DESCRIPTION | Z30100x31 | Z30100x40 |
| 1 | CAPACITY | ||
| DRILLING(CI) | 110 mm | 110 mm | |
| DRILLING(MS) | 100 mm | 100 mm | |
| BORING (MS) | 300 MM | 300 MM | |
| TAPPING (CI) | 50 MM | 50 MM | |
| TAPPING (MS) | 75 MM | 75 MM | |
| 2 | DRILLING HEAD | ||
| SPINDLE NOSE | MT6 | MT6 | |
| SPINDEL NOSE OUTSIDE DIA | 114 MM | 114 MM | |
| RAM DIA | |||
| TRAVEL OF SPINDLE | 500 mm | 500mm | |
| NUMBER OF SPINDLE SPEED MIN./ MAX. | 22 steps | 22 steps | |
| SPEED MIN-MAX | 8-1000 rpm | 8-1000 rpm | |
| NUMBER OF POWER FEEDS | 16 steps | 16 steps | |
| RANGE OF POWER FEED | 0.06~3.2 mm/r | 0.06~3.2 mm/r | |
| 3 | POWER | ||
| DRILL HEAD | 15 kw | 15 kw | |
| TWO SPEED MOTOR | NO | NO | |
| LIFTING ARM | 3 kw | 3 kw | |
| 4 | WORKING RANGE | ||
| COLUMN DIA | 600 MM | 600 MM | |
| DIST. FROM SPINDLE TO BASE.MIN-MAX | 700-2500 mm | 700-2500 mm | |
| DIST. FROM COLUMN TO CENTRE MIN-MAX | 560-3150 mm | 560-4000 mm | |
| DRILLING HEAD TRAVEL | 1300 mm | 1300 mm | |
| DRILLING RADIUS | 2590 mm | 3440 mm | |
| TRAVERSE OF ARM | 1300 mm | 1300 mm | |
| 5 | BASE PLATE | ||
| HEIGHT OF BASE PLATE | 360 MM | 360 MM | |
| WORKING SURFACE | 1250x800x560 mm | 1250x800x560 mm | |
| NUMBER/CENTRE DIST OF "T"SLOT | 5 | 5 | |
| | WIDTH OF CAST SIDE | 320 MM | 320 MM |
| OVERALL DIEMENTION | 479x178x258 CM 468x187x167 CM | 550x187 x258cm 552x186x172 cm | |
| 6 | WEIGHT | ||
| APPROX WT. | 20000 kgs | 22000 KGS |
