| No. | Item | Functions & Features |
| 1 | Motor | Self-developed tubular two-stage planetary gear reducer structure, driven by DC permanent magnet motor, compact structure, largetorque, low noise, and wear resistance. |
| 2 | Control System | The self-developed servo control system, precise control, more flexible running, less mechanical impact, and longer service life. |
| 3 | Technology | Frequency conversion technology, running speed adjustable, automatic opening when power off, meet different access requirementsand have a better experience. |
| 4 | Anti-push | Self-adaptive anti-push function, high transformation ratio gearbox, increasing torque for strengthening resistance and thestability, reducing the failure rate and cost pressure. |
| 5 | Wing | Acrylic or tempered glass is optional, shape, size, or color can be customized. |
| 6 | RS232 Communication Module | Support |
| 7 | Modbus Protocol | Support |
| 8 | Voice Function | Support |
| 9 | Trumpet | Optional |
| 10 | DC12V Backup Battery | Optional |
Technical Data:1. Working Temperature: -25ºC~+70ºC
2. Power Supply: AC110/220V±10%
3. Input Voltage of Controller: DC24V ±10%
4. Working Voltage of Motor: DC24V
5. Motor Power: 50W
6. Relative Humidity: 90% (no condensation)
7. Material of Cabinet: 304 stainless steel, sheet metal spraying process
8. Width of Passage: 600~1100mm (a pair)
9. Opening & Closing Speed: 0.2~1 seconds adjustable
10. MTBF: 10,000,000 times
