Sic Diesel Particulate Filter Substrate to Capture The Harmful Particulates Such as Soot and Ash

Product Description

Product DescriptionCordierite Diesel particulate filter substrateDiesel Particulate Filter (hereinafter called DPF) is designed to remove black smoke (soot, hereinafter called PM) form diesel engine exhaust, making great contribution to clean the exhaust gas from diesel cars while attracting much attention from worldwide car manufacturers.The most effective type is the so called wall-flow filter. Particulate matter is removed from the exhaust by physical filtration using a honeycomb structure similar to an emissions catalyst substrate but with the channels blocked at alternate ends. Our cordierite Diesel particulate filter substrate is made from modified cordierite ( 2MgO-Al2O3-5SiO2 )material. Current our full series has both 100 and 200 CPSI option and size is from 1.0 liters to 44 liters.
Product FeaturesFeature:· Low thermal expansion
· High filter specific surface area
· Low pressure drop
· Long-term durability performance
· High soot removal: >95%
· Excellent thermal shock resistance.
DPF InstallationA DPF is installed between an engine and a muffler to remove suspended particulate matter (SPM) from diesel engine exhaust gas.
The working principle of the particulate trap: By alternately blocking both ends of the pores of the honeycomb porous ceramic, the ceramic wall is used to filter and remove PM.
Product Size

Hole density	Shape	Dimension (mm)	Volume (Liter)
100 CPSI-200CPSI	Round	φ93×153	1.0394
		φ127×152.4	1.9308
		φ144×150	2.4432
		φ144×152.4	2.4823
		φ150×150	2.6511
		φ144×254	4.1372
		φ190×200	5.6713
		φ190×203	5.7556
		φ228×305	12.4542
		φ240×100	4.5245
		φ240×240	10.8588
		φ240×305	13.7997
		φ260×305	16.1954
		φ267×305	17.0792
		Φ286×267	17.1550
		φ286×305	19.5965
		φ286×355	22.8098
		φ286×381	24.4763
		Φ305×305	22.287
		Φ305×381	27.840
		Φ381×381	43.438
	Oval	188×103×145	2.2055
		207×101×200	3.282
	Racetrack	374×270×317	27.0537

Product picture:
Workshop :

---
