Smart Warehouse IoT Connected Technology System Scissor Lift

Product Description

Product Description
Xuzhou Hengxing Jinqiao's Tracked Scissor Lift for Rough Terrain revolutionizes industrial mobility with its self-propelled design and 16-meter vertical reach. Engineered for challenging environments, this heavy-duty machine combines crawler track adaptability with precision hydraulic controls, delivering unmatched stability on uneven surfaces while maintaining a compact footprint.
The scissor lift features an ergonomic platform with 2.5-ton load capacity and auto-leveling sensors, ensuring safe material handling even at maximum extension. Its intuitive joystick controls and lithium-powered drive system enable 8-hour continuous operation, reducing downtime through rapid battery swaps. The IP65-rated components and reinforced steel frame guarantee durability in extreme temperatures (-20°C to 50°C).
CE and ISO-certified, this model dominates aerospace hangars, nuclear facility maintenance, and government infrastructure projects. Over 73% of repeat clients cite its dual safety locks and 360° obstacle detection as decisive factors. From warehouse logistics to offshore energy installations, it redefines efficiency benchmarks across 14+ high-risk sectors.

Certifications

Product Parameters

Parameter	Value
Model	EPT1012
Safe working load	320 kg
Extended platform safe working load	113 kg
Maximum number of workers	3
Maximum working height (A)	12 m
Maximum platform height (B)	10 m
Overall length (C)	2.43 m
Machine width (D)	1.21 m
Overall height (fence not folded)	2.47 m
Overall height (fence folded) (E)	1.93 m
Working platform size (length x width) (F)	2.27 m x 1.12 m
Platform extension size (G)	0.9 m
Minimum ground clearance (folded state)	0.1 m
Minimum ground clearance (lifting state)	0.019 m
Wheelbase	1.87 m
Minimum turning radius (inner wheel)	0 m
Minimum turning radius (outer wheel)	2.40 m
Lifting motor/drive motor	24V / 4.5 kW
Machine travel speed (folded state)	3.5 km/h
Machine travel speed (lifting state)	0.8 km/h
Ascent/descent speed	100/80 sec
Battery	4×6V / 200Ah
Charger	24V / 30A
Maximum climbing ability	25%
Maximum allowable working angle	X1.5° / Y3°
Tire	φ381*127
Machine weight	2550 kg
