Pb-80 Double Motors Automatic Plate Milling Machine Milling Width 70mm

US$6,180.00 1 set (MOQ)

Basic Info.

Model NO.
PB-80
Cutting Material
Copper, Carbon Steel, Iron, Aluminum, Metal Alloy, Stainless Steel
Automatic Grade
Automatic
Power Source
Electric
Cutting Mode
Plasma Cutting
Power
380V 50Hz
Total
4800W
Milling Width
0-70mm
Single Milling Width
15-20mm
Slope Angle
0-60 Degree(Adjustable)
Clamp Thickness
6-60mm
Clamp Width
>100mm
Process Length
>300mm
Worktable Height
820-860mm
Net Weight
250kg
Processing Material Materials
Carbon Steel,Stainless Steel,Aluminum Alloy etc...
Transport Package
Wooden Case
Specification
1310*760*690mm
Trademark
Wellnit
Origin
Zhejiang, China
HS Code
8461909000
Production Capacity
80 Sets/Weeks

Product Description

PB-80 Double motors Automatic Plate milling machine milling width 70mm
Main Features:
The Machine bevel the steel, plate, stainless steel and aluminum automatically, which have big difference with milling machine in the market. We provide customer stable products.
The PB-80 type edge milling machine:
1. Machine parts:Anti-corrosion,hardening and tempering,abrasion treatment;
2. Welded parts: Stress relief treatment, deburring treatment, high temperature paint treatment;
3. More safe: The Control box is separate from the Electrical box, high voltage power supply do not
contact with operation interface.
Technical parameters:
power 4800w clamp width >100mm
voltage 380V 50HZ slope angle 0-60 deg(adjustable)
spindle speed 750-1050r/min clamping thickness 6-60mm
feed speed 0-1500mm/min worktable height 820-860mm
milling width 0-70mm net weight 250kg
single milling width 15-20mm processing materials carbon steel,stainless steel,aluminumalloy,composite plate
processing length >300mm

Specification:
Product packaging
1.How to choose a suitable model?
RE: Before choose the model,we need to know more details about the pipe,such as the
I.D,O.D,wall thickness,the material of the pipe and the enviroment of the site and the requirement of the end face. Then it will be more convient for all of us to make an immediately decision .Thanks!
2.Do you have another choice about the driven?
RE: Of course,we have widely variety of choices for you, such as the electric,pneumatic, hydraulic and NC.
3. About the type of the beveling?
RE: The normally type is the v and U,if you have any special requirement, please let us know it, i believe that our engineer can provide a solution for you.
