Hb67V 67m Concrete Pump Truck for Sale

Product Description

HB67V 67M Concrete Pump Truck for Sale
Product Description • Compact in design, 49m pump mounted on a 4-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 6 arms with unfolding height 9.5m only,which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor, itmonitors the pump intelligently on working data management,real-time diagnostics, alarm logging, and service interval notice.
• Rich in configurations and high quality components.
• Boom with damping technology.
• Stabilization control on boom.
• Multilingual man-machine interface system.
• PWM+CAN dual communication mode remote control.
Technical Parameters

CATEGORY	ITEM	UNIT	HB67V
Overall	Outline dimension	mm	15815×2550×4000
	Oerall weight	kg	53870
Chassis	Brand	/	Sinotruck
	Model	/	ZZ5546V52MF1B
	Wheelbase	mm	1950+5200+1400+1500
	Max.power	kW	397
	Emission standard	/	China VI
Pumping system	Theoretical	m³/h	180
	Concrete pumping pressure	MPa	10.2
	Theoretical pumping times	/min	22~24
	Delivery cylinder diameter × stroke	mm	φ260×2200
Placing boom	Reach height	m	66.1
	Reach depth	m	48.6
	Slewing radius	m	60.9
	Slewing angle	°	±270
Others	Transfer	/	S valve

Product Pictures
