Model
| 2040
|
Power source
| machine:AC220V/50hz, plasma cutter: AC380V/50hz
|
Effective cutting width
| 2000mm
|
Effective cutting length
| 4000mm /6000mm ( accept tailor-made length)
|
Cutting process
| plasma/ flame
|
Cutting thickness(flame)
| 6.0-150mm (oxygen+acetylene or propane)
|
Cutting thickness(plasma)
| 0.5-40mm Depending on the customer's plasma power supply
|
Cutting speed
| 20-3500mm/min (max.4000mm/min)
|
Cutting accuracy
| ±0.5m
|
Torch lifting distance
| ≤80mm
|
Gas pressure
| Max 0.1Mpa
|
Oxygen pressure
| Max 0.7Mpa
|
Applicable gas type
| Oxygen and propane or acetylene
|
Working interface
| Chinese and English (other languages can be customized)
|
Duty cycle
| 24hours
|
Software
| Starcam ,Fastcam
|
Control System
| Fangling
|
CAD drawing conversion
| nesting cut code
|
