SG60160SD SG60160CNC SG60220SD SG60220CNC CNC Column Moving Surface Grinder machine

Product Description

FEATURES: SG60160SD CNC LARGE SIZE SURFACE GRINDING MACHINE
STANDARD ACCESSORIES:
Coolant tank, Wheel dresser base, Flange and wheel extractor, Build in electro magnetic chuck controller, Balance stand,
Working lamp, Balance arbor, Standard wheel, PLC grinding controller, CNC controller (only for CNC series machine),
Leveling wedge and foundation bolt;
OPTIONAL ACCESSORIES:
Electro magnetic chuck, Hydraulic parallel wheel dresser, Coolant with magnetic separator and paper filter, Coolant tank paper filter,
Coolant tank with magnetic separator
SD MEANS:
NC servo motor is used on cross and vertical movement, hydraulic drive longitudinal movement. Equiped with PLC auto grinding controller.
CNC MEANS:
Numerical control of cross and vertical, two axes linkage, and hydraulic drive on longitudinal. Also according to customer's request,
the machine can realize 3 axes linkage by servo control of X axis.
SPECIFICATIONS:

SPECIFICATION		UNIT	SG60160SD	SG60220SD	SG60300SD	SG80160SD	SG80220SD	SG80300SD
			SG60160NC	SG60220NC	SG60300NC	SG80160NC	SG80220NC	SG80300NC
Table size		mm	610x1600	610x2200	610x3000	810x1600	810x2200	810x3000
Max. grinding (WxL)		mm	610x1600	610x2200	610x3000	810x1600	810x2200	810x3000
Max. distance from table to spindle center		mm	820
Magnetic chuck size (optional equipment)		mm	600x800x2	600x1000x2	600x1000x3	800x800x2	800x1000x2	800x1000x3
Speed of table longitudinal movement		m/min	5~25
Wheelhead cross movement	Auto feed	mm/t	1~30
	Rapid speed	m/min	0.05~2
	Feed of handwheel	mm/div	0.005
Wheelhead vertical movement	Auto feed	mm/t	0.005~0.05
	Rapid speed	mm/min	0.05~2
	Feed of handwheel		0.005
Wheel	Speed	Rpm	960
	Size (ODxWxID)	mm	500x75x305
Motor of spindle		kw	18.5
Max. loading capacity of table (include chuck)		kg	1230	1690	2300	1630	2240	3060
Total rated power		kw	28.5				28.5	31
Height of machine		mm	2700
Floor space (LxW)		mm	4700x3000	6000x3000	8200x3000	4700x3500	6000x3500	8200x3600
Gross weight		kg	8500	9500	12500	10000	11500	14000
