Multifunction CNC Mill 5 Axis Vmc1160 for Metal with 5.5kw Spindle CNC Milling Machine Center

Product Description

Product Description
VMC1160 vertical machining center

1. Parts processing has strong adaptability and flexibility, and can process parts with particularly complex contour shapes or difficult-to-control dimensions, such as mold parts, shell parts, etc.;
2. It can process parts that cannot be processed or are difficult to process with ordinary machine tools, such as complex curved parts described by mathematical models and three-dimensional space surface parts;
3. It can process parts that need to be processed in multiple processes after one clamping and positioning;
4. The processing accuracy is high and the processing quality is stable and reliable. The pulse equivalent of the CNC device is generally 0.001mm, and the high-precision CNC system can reach 0.1μm. In addition, CNC processing also avoids operator errors;
5. The high degree of production automation can reduce the labor intensity of operators. Conducive to the automation of production management;
6. High production efficiency. CNC milling machines generally do not need to use process equipment such as fixtures. When replacing workpieces, they only need to call the processing program, clamping tool and tool adjustment data stored in the CNC device, thus greatly shortening the production cycle.
Secondly, the CNC milling machine has the functions of milling machine, boring machine, and drilling machine, which highly centralizes the process and greatly improves production efficiency. In addition, the spindle speed and feed speed of CNC milling machines are continuously variable, so it is conducive to selecting the optimal cutting amount.
Product Parameters

cnc vertical machining center			VMC1160
Table	Area	Unit	1200*600 mm
	T-slot	mm	5-18-100
	Max. load	kg	800
Travel	Moving range X, Y, Z	mm	1100×600×600
	Spindle nose to table surface	mm	120-720
	Spindle center to column guideway	mm	650
Feed	Rapid feed speed X, Y, Z	m/min	36/36/30
	Cutting speed	mm/min	1~10000
Spindle	Taper		BT40
	Speed	r/min	(AC servo) 10~10000
	Motor Power	kW	11/15
Tool magazine with capacity		qty(pcs)	24
Accuracy	Positioning accuracy	mm	±0.008
	Re-positioning accuracy	mm	±0.005
Overall dimension		mm	3300*2400*3000
Machine weight		kg	6300

FAQ
Q1. Could I put my LOGO on it or paint my own color?
A: Yes, As long as the order quantity reach to the MOQ.
Q2. What's your trade terms?
A: FOB, CIF, DAP or other terms are acceptable.
Q3. Could I order trail small order?
A: Yes,we have no MOQ for standard version products. The price is different from different order quantity.
Q4. What points need to be confirmed before placing the order?
A: Voltage, frequency, plug type trade term and have shipping agent or not.
Q5. What is your terms of payment ?
A: Payment≤1000USD, 100% in advance. Payment≥1000USD, 30% T/T in advance, 70% before shippment. If you have another question, pls feel free to contact us as below.

---
