| Overall dimensions | ||
| Length 4050mm | width 1900mm | |
| Height 1630mm | Weight (without holder) 8500kg | |
| Main specification | ||
| Max producing taper 1:4 | Max.swing over bed 1000mm | |
| The pipe diameter 114-350mm | Maximum machining length 1500mm | |
| The taper device travel of moving 930mm | ||
| Spindle | ||
| Spindle forward speed grade 9 | The range of speed 6.6-198r/min | |
| The main shaft reverse of speed grade 3 | The range of speed 13.5-200.9r/min | |
| Spindle bore 350mm | ||
| Feed specification | ||
| Aspect to the number of species 32 | ||
| Per revolution of spindle feed range | Transverse 0.04-0.72mm Longitudinal 0.1-1.44mm | |
| The number of metric thread processing 24 | Processing inch thread pitch 24 | |
| Processing metric thread pitch 1-15mm | Processing inch thread pitch 1-15t.p.i | |
| Rapid traverse longitudinal saddle 4m/min | ||
| Sliding box hand wheel rotary and sliding base travel 1mm | ||
| Knife rest rotary per time the knife rest travel. 0.05mm | ||
| Bottom slide rotary per time travel 0.05mm | ||
| Spindle and knife distance 33mm | ||
| Tailstock | ||
| Diameter sleeve top 100mm | Top sleeve travel 250mm | |
| Taper sleeve top Morse6 | The amount of lateral movement of tailstock ±15mm | |
| Taper Morse 6 | ||
| Power | ||
| Main power Y180M-4 18.5KW 1470r/min 380v | Main motor belt B1727 | |
| Fast electric NY80-4 1.1KW1350r/min 380v | Clamping motor: YXZ90-L-4 1.5KW 1400r/min 380v | |
| Gear pumps CB-B6 2.5Mpa 1450r/min | ||
