High Definition-Power Line Communication KS700Q

Product Details

Product Description

Product Description
High Definition-Power Line Communication KS700Q
Robot DC type
Products Features:
● Intelligent age,hundred megabit bandwidth,stable signal,robot dedicated.
● The power supply voltage of the carrier KS700Q is DC12 ~ 24V / 1A, which supports DC or any
two-core line carrier communication below 56V.
● PLC channel port wiring needs to distinguish between positive and negative poles.
● The carrier supports bus, star, tree, and hybrid network topologies structure.
● Set up the masterslave machine to ensure that the power supply is matched and the wiring is correct
before powering on.
● Do not operate energized, do not touch the output terminal directly, do not connect the output terminal
short or connected to the housing.
Technical data:

Category	Classification	Technical indicators
Power supply	DC Power supply	DC: 12-56V More than 1A
Performance parameter	Modulation type	OFDM modulation type
	Transmission distance	Power line point-to-point 500 meter
	Ethernet	10Mbps/100Mbps self-adaption
	Multicast	Support IGMP multicast protocols
	Way of encryption	AES-128bit
	Overall power consumption	≤3W
	Physical Layer / Effective propagation distance	240M/92Mbps
	Transmisson medium	Any two-core wire, such as power line, twisted pair. coaxial line, parallel line etc.
Environmental requirement	Operating temperature	-40℃～85℃
	Operating humidity	20%-95%（No condensation）
	Storage temperature	-40℃～85℃
External dimension	Colour	Black
	Size	Length,width and height are：94.5*71*26.5mm
	Net weight	250g

Exterior dimensions:

PLC KS700Q’s length, width and height are：94.5x95x26.5 mm(with fixed ear)，four fixing holes on both fixing lugs，
fixed with M3 screws.Without fixing lugs size is：94.5x71x26.5mm，can be fixed with cable ties or double-sided tape.
Applications:
It has been widely used in all walks of life，including slide rail robot, inspection robot, pipeline robot,
underwater robot, high-definition video surveillance and so on.

---
