Cut to Length Line for Steel

Product Description

cut to length line for steel
Advantage of cut to length line for steel
1.This cut to length line for steel adopts steel welded structure, hydraulic transmission,easy to operate, reliable performance, nice appearance.
2.Blade gap is adjusted according to sign post, can adjust light quickly.
3.It has light for wire device, and can non-polar adjust route.
4.It adopts fence type safety device.
5.Size of rear block stop and shearing numbers has digitaldisplay apparatus.

No.	cut to length line for steel
1	Suitable to process	PPGI,galvanized sheet,carbon steel and stainless steel plate
2	Thickness of raw material	Slitting :Max 0.8mm Cutting:Max 6.0mm
3	Roller station	Up :6 rollers Down:7 rollers
4	Voltage	380V,50HZ,3Phase
5	Main frame	400 H beams
6	Side-wall thickness	60mm
7	Diameter of shaft	¢130mm
8	Chain size	1.2Inch
9	Motor power	7.5kw(Siemens)
10	Touch screen/PLC	Siemens
11	Transmission	Gear transmission
12	Machine size	2800x2000x2000m
13	Machine weight	About 3.8Tons

cut to length line for steel picture
cut to length line for steel after sales services
1. Warranty :One year,and we will provide technical support for whole life of the equipment.
2. Delivery time: Within 25 days after deposit receipt your payment
3. Guarantee period: 24months free service/ pay service all the machine life
4. Installation and training If buyers visit our factory and check the machine, we will teach you how to install and use the machine and also train your workers/technician face to face.
