| Item | Traditional Welding | Last Generation Laser | Our New Generation Laser Welding |
| Heat Input | Very High | Low | Low |
| Workpiece Deformation Undercut | Big | Small | Small |
| Bonding Strength to Base Material | Normal | Normal | Good |
| Process after Welding | Polishing | No Need Less Polishing | No Need Less Polishing |
| Welding Speed | Normal | More Than TIG Welding | More Than Double TIG Welding |
| Suitable Materials | Stainless Steel Carbon Steel Galvanized Sheet | Stainless Steel Carbon Steel Galvanized Sheet | Stainless Steel Carbon Steel Galvanized Sheet |
| Consumables | More | Less | Less |
| Operation Difficulty | Complicated | Normal | Easy |
| Operator Safety | Not Safe | Safe | Safe |
| Environmental Protection | Not Environmental Friendly | Environment Friendly | Environment Friendly |
| Oscillating Welding | None | None | None |
| Spot Width Adjustment | None | None | None |
| Welding Quality | Bad | Normal | Good |
| Item | Parameter | |
| Model | 1500 | 2000 |
| Item Name | Handheld Fiber Laser Welding Machine | Handheld Fiber Laser Welding Machine |
| Laser Power | 1500w | 2000w |
| Laser Wave Length | 1070nm | 1070nm |
| Fiber Length | 10/15m | 10/15m |
| Working Way | Continuously/Modulation | Continuously/Modulation |
| Welding Speed Range | 0-120 mm/s | 0-120 mm/s |
| Colling System | Industrial Thermostatic Water Tank | Industrial Thermostatic Water Tank |
| Protection Gas | Argon&Nitrogen | Argon&Nitrogen |
| Air Pressure | Welding>3bar Cutting>4-7bar | Welding>3bar Cutting>4-7bar |
| Working Environment Temperature | 15-35°C | 15-35°C |
| Working Environment Humidity | <70% No Dewing | <70% No Dewing |
| Recommended Thickness | 0.5-3mm | 0.5-5mm |
| Welding Gap | ≤0.5mm | ≤0.5mm |
| Voltage | AC220V | AC220V |
| Weight | 168kg | 200kg |
| Measurement | 900*670*975mm | 1050*720*975mm |
