| US$25,000.00 | 1 Piece (MOQ) |
| Category | Item | Unit | Parameter | |
| Dimension | Overall length | mm | 11850 | |
| Overall height | mm | 3900 | ||
| Overall width | mm | 2500 | ||
| Wheel base | Axles 1 and 2 | mm | 4500 | |
| Axles 2 and 3 | mm | 1350 | ||
| Tread | Front axle | mm | 2053 | |
| Rear axle | mm | 1802 | ||
| Weight | Weight with full load | kg | 23850 | |
| Axle load | Front axle | kg | 6000 | |
| Dual rear axles | kg | 17850 | ||
| Travel performance | Max. travel speed | km/h | 85 | |
| Min. turning diameter | m | ≤20.3 | ||
| Approach angle | ° | 17 | ||
| Departure angle | ° | 10 | ||
| Braking distance(at 30km/h) | m | ≤10 | ||
| Min. ground clearance | mm | 204 | ||
| Max. gradeability | % | ≥25 | ||
| Main performance | Rated working height | m | 32.5 | |
| Rated load | kg | 400 | ||
| Max. working radius | m | 19 | ||
| Outrigger span(longitudinal×lateral) | m | 6000×5800 | ||
| Elevating range | ° | -3~80 | ||
| Working speed | Boom deploying time | S | ≤150 | |
| Outrigger extending time | S | ≤30 | ||
| Slewing speed | r/min | 0~1.5 | ||
| Fire-fighting performance | Water monitor rated flow | L/s | 50 | |
| Water monitor rated pressure | MPa | ≤1.0 | ||
| Water monitor rated reach | m | ≥65 | ||
