| HUAFENG DOUBLE LAYER THERMAL CTP PLATE | |
| Clio Series | |
| PLATE | Positive Double Layer Thermal CTP plate fit for extreme printing condition with both normal ink and UV ink without baking. |
| GAUGE | 0.15,0.20, 0.25, 0.30,0.40 (mm) |
| COLOR | Blue |
| SPECTRA SENSITIVITY | 800 - 850 nm |
| PLATESETTER COMPATIBILITY | Any Thermal platesetter in the market |
| LASER ENERGY | 100 - 110 mj/cm2 |
| RESOLUTION | 1% - 99% at 200 lpi |
| DEVELOPER | Huafeng FTP-DX, Kodak Goldstar Premium etc. |
| PROCESSING | 20 seconds developing time at temperature 23-25℃ |
| BAKING | No need baking due to it’s high chemical and UV ink resistance |
| RUN LENGTH | Normal ink: 100,000 - 200,000 impressions unbaked. UV ink: 50,000 - 100,000 impressions unbaked (Actual run length may vary according to press, ink and paper conditions.) |
| SAFE LIGHT | Within 2 hour under white light |
| SHELF LIFE | 24 months under recommended storage conditions |
| PACKAGING | Available in all standard pallets, fit for bulk and full container loading. |
| TRANSPORT AND STORAGE | Unopened plate packs should be stored flat and away from excessive cold, heat and humidity. Use in a controlled environment of 10-30 ℃ and 40%-65% RH, non- condensing. |
