New Condition Low MOQ Nano Bead Mill for Carbon Nanotube Slurry

Product Description

Basic Info.

Model No.	SMN90	Scraper	gearbox, speed 0-12rpm
Principle	Large Flow Nano Grinding Machine	Chamber	150L
Finished Surface	Solvent-resistant paint, dark blue	Batch Size	1000-4000L
Tongs' Features	Adjustable Tongs	Power	Dual Power
Fineness	30nm-5um	Output	Siemens Screen
Operation	380V/50Hz/3 phases	Power	250kw
Transport Package	Wooden Case	Trademark	Hoosun
Origin	Shanghai, China	HS Code	847982

Performance Advantage 01
The dual power centrifugal nano bead mill is designed based on the principle of (screen free) centrifugal separation. The centrifugal separation has an independent power motor. During machine operation, most of the grinding zirconium balls are distributed around the periphery of the grinding chamber and move in the same direction as the object due to the centrifugal force of the disperser, A small amount of zirconium balls and materials rotate around the separator. The separator generates a centrifugal force on the zirconium balls at high speed, which is greater than the pressure generated by the pump on the zirconium balls in the chamber, keeping the zirconium balls in the grinding chamber. At the same time, the separator generates a centrifugal force on the materials at high speed, which is less than the pressure generated by the pump on the chamber materials, forcing the materials to flow out of the separator. The grinding cylinder adopts silicon carbide material with good wear resistance and thermal conductivity, thus having a stronger application range.
02
Fineness: 50 - 150nm
Zirconia Bead Dia.: 0.03-0.6mm
Separation system: Centrifugal separation
Optional materials: Tungsten carbide/Polyurethane/Zirconia/silicon carbide/Silicon nitride
03 Ultrafine nano rod pin high-efficiency grinding machine, with a grinding fineness of less than 100nm, independent operation of material grinding and material separation, and more precise and thorough grinding. The effective output per unit time is 2-3 times that of ordinary sand mills.
04
Application: Nano new materials, MLCC, Lithium batteries, Silicon carbon cathode electrodes, Alumina, Ceramic ink etc.
Company Profile

Hoosun Workshop
Exhibition
Production Line Projects
CE & ISO certification
Signing Ceremony & After-sales service
Our Customers
FAQ

Q1: How do l order?A: Make an inquiry to us →Inform us of the use scenario → Receive our product design recommendation→Discuss details→Confirm sample → Sign contract/deposit→ Mass production →Goods ready -→Balance/delivery →Further cooperation.Q2: What about your warranty?A: First of all, before dellvery, our in-house QC will do a comprehensive inspection to show the condition of the goods by testing operation or trial operation. Secondly, our warranty is 12 months from the time of arrval. If the equipment fail, such as the motor, reducer or inverter is damaged, we will replace and repair it free of charge. In case of damage caused by operational error, we will provide technical guidance to customers.Q3: How about your after-sales service? What should I do if something goes wrong during use?A: Whether it is under warranty or not , we will first help you figure out the essence and solve the problem through video conferencing. lf it is under warranty, no doubt we will take care of the problem and provide a new replacement free of charge. If it exceeds the warranty period, we will replace it for you with it cost price, find the most favorable mode of transportation, thereby solving the problem, maximizing your cost savings at the sametime, and provide lifelong maintenance advice and technical guidance.Q4: What are your company's strengths? Because l see that most of the products look very similar.A: Yes , you're right. Similarity of appearance is a problem.In this matter,we mainly do two aspects of work: firt, to ensure the quality of products; in the other hand, improve the professional quality of sales representatives, improve their communication skills, and provide customers with more additional value beyond the product.
Q5: How can l trust you? After all, this is our first cooperation, but I must give you the money before you ship the goods.A: Yes, it's really not easy to choose a reliable supplier among so many suppliers.Because you may have to consider many factors, such as quality safety, price, delivery after-sales service and so on. But don't worry, our company has more than 12 years of experience in this field and we have taken all the factors into consideration for you.
The only thing you need to think about is how to continue to grow in your market, and we'll do the rest.Q6: Can it be customized?A: Yes, the equipment can be customized according to customers' requirements.

---
