4K UHD H1 Series Video PTZ Cameras delivering 3840X2160@30fps which is equipped with 0x,3x, or 10x Optical zoom block optional, Wide view angle provide the Ultimate Experience to Optimize Video Collaboration.
Wide view angle provide the Ultimate Experience to Optimize Video Collaboration
Features Equipped with 1/2.5"HD color SONY CMOS, HOV 105 Degree Single USB2.0 Cable delivering quality video, PTZ movement & power supply 9 Presets Call/Set/Clear operation in remote control unit Ideally suited to Small business group meeting rooms
| Model # | H1-L3M-4K |
| Sensor | 1/2.5″HD Color CMOS Sensor, 3864 (H) × 2202 (V) approx. 8.51 M pixels |
| Min Scene illumi. | 0.5Lux at F2.0 |
| White Balance | AUTO |
| IRIS | F1.35-F2.4 |
| Lens | 3.5mm (W) ~ 9mm (T) Stepping Motor Zoom |
| Zoom | 3x Lens Zoom Stepping focus |
| Horizontal field of view | FOV: 100~39° Vertical : 71~22° |
| Operation System | Windows XP, Windows Vista, Windows 7/8/10, Mac OS X, Linux |
| USB Interface | USB 2.0 type B female jack |
| Video Compression | MJPEG |
| Video format | 3864 (H) × 2202 (V) approx. 8.51 M pixels, 1080p@30fps/25fps, 720P@30fps/25fps, 640*480,640*360 |
| USB to RS232 Control | Support USB to RS232 via VISCA Commands for PTZ Control |
| Control Protocol | VISCA, Pelco-D |
| Baud Rate | 9600/38400bps |
| Preset | 64 |
| Speed Matching Function | Support |
| H & V Image Flip | Support |
| Pan Speed Range | 1-40 degrees/s |
| Pan Rotation Angle | ± 165° |
| Tilt Rotation Angle | + 30° , - 30° |
| Auto Pan Scan | Support |
| Remoter Control | IR Wireless remote control P/T/Z |
| Power Supply | USB2.0 USB cable for power supply (USB accessory power supply) |
| Operation Temperature | 0ºC~50ºC |
| Environmental humidity | 0-95%RH (non-condensation) |
| Length X width X high | Camera unit: L 180mm x W 112mm x H129mm |
| | Package: 302mm x 218mm x 120mm |
| Weight | 580g |
