| Negotiable | 1 Piece (MOQ) |
| NO | |||
| 1 | Containers material | Non-metallic containers: plastic / glass / ceramic, metal containers: aluminum, iron | |
| 2 | Size of the containers | 1. Plastic / glass / ceramic: Volume: not less than 100ml, height not less than 3cm Diameter: more than 30mm less than 200mm Maximum height: no limit Wall thickness: no more than 8mm 2. Metal container: Volume: not less than 100ml, height not less than 3cm Diameter: more than 30mm less than 150mm Maximum height: no limit Wall thickness: no more than 0.5mm | |
| 3 | Dangerous Liquid Detectable | The instrument is capable of alarming the following flammable or hazardous liquids in sealed containers: 93# gasoline, kerosene, diesel, ether, diisopropyl ether, petroleum ether, acetaldehyde, ethylene glycol, nitrobenzene, propylene oxide, n-heptane, pine perfume, acetone, benzene, toluene, xylene, dichloro Ethane, ethanol, isopropanol, 70% ethanol, carbon disulfide, methanol, nitromethane, 70% isopropanol, Paint thinner (nitro thin solvent), tetrahydrofuran, paint,Hexane, hydrochloric acid, sulfuric acid, nitric acid | |
| 4 | Volume requested | Not less than 100ml, height not less than 3cm | |
| 5 | Time of testing | Single piece of liquid item detection time is less than 8 seconds Insulated container (plastic, glass, ceramic container): less than 1 second Metal container (aluminum can, iron can): less than 4 seconds | |
| 6 | Max. Power consumption | Less than 20W | |
| 7 | Data Storage | Stores no less than 10,000 tests results, and can export data through standard USB interface, read and analyze through PC software | |
| 8 | Insulation resistance | Between the source plug or the power inlet and the bare metal part of the housing Insulation resistance, not less than 100 MΩ at normal temperature; after damp pretreatment with relative damp heat of 91% to 95%, temperature of 40 ° C, 48 hours, equipment The insulation resistance is not less than 2MΩ. | |
| 9 | Leakage current | The leakage current of the equipment during working in accordance with the safety requirements of electronic equipment, less than 5mA | |
| 10 | Weight | Around 8.3Kg | |
| 11 | Working Temperature | -10ºC~55ºC; 0%~90% | |
| 12 | Pressure | 86kPa~106kPa | |
| 13 | Power supply | AC 180V-240V (50/60Hz) |
| NO | |||
| 1 | Time Setting | Set the time for the equipment | |
| 2 | Password settings | Modify the initial password | |
| 3 | Adjust contrast value | Set the brightness of the LCD screen. The higher the value, the brighter the screen. | |
| 4 | Device ID | Display device ID, find settings information | |
| 5 | Restore settings | Enter password to restore factory settings | |
| 6 | IP setting | Communication with the host computer through the network interface and USB interface | |
| 7 | Switch account | Identify the user who is currently operating the system, and then save the detection result combined with the user name. | |
| 8 | Language selection | Switching between English and Chinese | |
| 9 | Equipment parameters | for after-sales engineers to set the parameters according to the specific environment | |
| 10 | Firmware version | Indicates the current version and for further upgrading | |
| 11 | Accuracy adjustment | Adjust the recognition accuracy of the software by setting the value | |
| 12 | Self-checking | When there are a lot of false alarms, use this function to improve the inspection accuracy of the machine | |
| 13 | Alarm sound | switch on/off sound alarm | |
| 14 | Alarm reset mode | Select alarm rest whether when the object to be removed not when not removed | |
| 15 | Alarm Indication | sound, light, LCD display alarm |
| NO | |||
| 1 | Screen | Top Micro, LM240160CCW, 240x160 black and white LCD | |
| 2 | Main board | Control-E | AT |
| 3 | RF power amplifier board | AT1000-PA-D | AT |
| 4 | RF receiver board | RX-C | AT |
| 5 | RF transmitter board | TRA-E(printed as TAR-E) | AT |
| 6 | Antenna board | Tianhe-antenna | AT |
| 7 | Heating film | AT1000II, JIAREMO,Version: G | |
| 8 | Thermocouple | Taiwan Taishi, NR81531B | |
| 9 | Keyboard | DeZhongHeng, K38-1, 78x98mm, English |
| NO | List | Quantity | |
| 1 | AT1000II-2 Detector | 1 | |
| 2 | 1.5m USB cable | 1 | |
| 3 | 2m power cable | 1 | |
| 4 | 2m Crossover internet cable | 1 | |
| 5 | Accessories box | 1 | |
| 6 | Manual, certificate / warranty card | 1 | |
| 7 | 250MLPlastic sampling cup | 1 |
