Losses in Pipe Systems Fittings Fluid Mechanics Lab Equipment Vocational Training Equipment

Product Description

ZM8127 Losses in Pipe Systems Fittings Fluid Mechanics Lab Equipment Vocational Training Equipment Teaching Equipment
"Specification
Panel for the demonstration and visualization of friction loss
• Investigation of the friction loss in pipe constrictions, elbows, bends, fittings
• 13-tube manometer
• Circulating pump, 3 stages, max. 60W
• 13-tube manometer 1600mmWC
• Flow rate measuring range: 0...1000ltr/h
• Supply tank: approx. 5ltr
• Circulating pump:
• Max. flow rate: 60ltr/min,
• Max. head 4m
"
Pipe diameter: 19.48mm
Differential pressure gauge: 0 to 1.4bar
Enlargement diameter: 26.2mm
Contraction diameter: 19.48mm
Fittings:
- 45° mitre
- 90°elbow
- short bend
- large bend
- enlargement
- contraction
Manometer range: 0 to 440mm
Number of manometer tubes: 12
Flow rate measuring range: 0...1000ltr/h
EXPERIMENTAL CAPABILITIES
¨ measuring the losses in the devices related to flow rate and calculating loss coefficients related to velocity head
¨ comparing the pressure drop across each device
Brand: Shouldshine
Model:ZM8127
(Educational Equipment Teaching Equipment Vocational Training Equipment For engineering university, higher education college, polytechnics, technical institute, engineering training center, technical secondary school.)
Product Details and Warranty
We supply suitable spare pats according to experiment requirement, our products take aluminum structure, A4 paper dimension aluminum and plastic hanging box structure.
We supply 3 years warranty time. Please se photo for foreign sales department and photo for spare parts.

Packaging & Delivery
Package details: plastic film+ plastic foam + plywood box with pallet, and for equipment dimension less than 1CBM, we supply plastic film+ plastic foam+ fine carton.
Arrange delivery within 45 days upon receipt of payment.
Please see below photo for detailed package.

Company Information
We supply professional educational training equipment and technical teaching equipment, which has been widely applied in Engineering Universities, Polytechnics, Technical Institute, Vocational Schools as well as Industry workforce Development Programs and Training Center. Our products allow students to learn and experiment through valuable hands-on experience, and the technology covered by our training equipment provides knowledge, experiments and didactic skills development that are of critical importance to today's and tomorrow's careers.
Service
We supply supply7*24 hours service, customer design service, OEM service, buyer label service. With professional engineers team and sales team, we assure you good product quality.
Certificate
Our products takes ISO9001 product management system.

---
