| TECHNICAL SPECIFICATIONS |
| Effective width | 190,220,230,250,260,280,340,360,400cm |
| Effective width reduction | 190cm: at least 70cm |
| 220 and 250cm:at least 90cm |
| 280,340,360and400cm:at least 96cm |
| Weft color selection | Up to 8 colors |
| Double or multiple weft insertion |
| Weft feeder | Adjacent yarn loops |
| Separating yarn loops |
| Automatic switch function of weft feeder |
| Positive weft tensor | Programmable weft tensor |
| Balloon limitor |
| Weft detection | Electronic weft scissors,each Channel can set the cutting time separately |
| Yarn change detector |
| Fixed and oscillating main nozzle |
| Auxiliary nozzle |
| Lenado's knot removal decive |
| Beam | 800,914,1000,1100mm |
| Back-beater | Universal type with built-in warp tension sensor |
| | Stable mechanism |
| Stop device | 6 electonic drop bars |
| | 25mm pitch or 8 drop bars |
| | 16mm pitch detection strip by strip |
| Take-up device | Roll diameter |
| | Direct take-up by pressing rollers |
| Main motor | The main motor directly drives the loom |
| | Intelligent frequency conversion control vehicle speed |
| Reed movement | Conjugate cam,with cam follower |
| Shedding | Positive dobby shedding for up to 16 shafts heald frame |
| Positive cam shedding for up to 8 to 10 heald frames |
| Cam mechanism with automatic levelling function |
| Heald frames for 330mm(13 o'clock) heald wire |
We are a professional manufacturer holding our own International Trade Department,for that we can understand customer's needs and offer a reasonable price.
we do welcome our new and old friends come here to have a visitation.Besides,we would send you our exposition and relative informantion to promote a face-to-face meeting if you'd like to
.
We offer reasonable price for every client,and the price is changeable according to purchasing amount.
The main subassembly and raw materials are all supplied by large companies.Key parts are research and developed by our own staff.Professional assembly line work and strict quality test system can ensure your high quality requirement.
We offer engineers available to service overseas under merchandisers supervision and translation.
