| Model | YSD-TGD-50W | YSD-TGD-100W | YSD-TGD-150W | YSD-TGD-200W |
| Power | 50W | 100W | 150W | 200W |
| Input Volt | 100-277V/277-480V/AC 50/60Hz |
| Led Type: | 3030SMD |
| Led(pcs) | 64pcs | 128pcs | 192pcs | 256pcs |
| Power Factor: | >0.98 |
| Power Efficiency: | >92% |
| Driver | MEANWELL, INVENTRONICS,SOSEN, according to customer needs |
| Ra | Ra>80 |
| Lumen(Lm/W) | 140lm/W |
| Control method | Ordinary, 0-10V, PMW, DALI,Photocell sensor |
| Light body material | Die-casting aluminum lamp body + PC Lens +304 stainless steel screws |
| Beam angle | 60/90/60*150Deg |
| CCT: | 3000K/4000K/5000K/5700K/6500K |
| Protection level | IP66/IK09 |
| Installation | Adjustable angle bracket installation |
| Lightning protection level | 10KV or 20KV, according to the actual needs of customers |
| Work temp | -35ºC~65ºC |
| Work humidity | 10%~90% |
| Warranty/Life | 5years/50,000hrs |
| Model | YSD-TGD-250W | YSD-TGD-300W | YSD-TGD-400W | YSD-TGD-500W |
| Power | 250W | 300W | 400W | 500W |
| Input Volt | 100-277V/277-480V/AC 50/60Hz |
| Led Type: | 3030SMD |
| Led(pcs) | 320pcs | 384pcs | 512pcs | 640pcs |
| Power Factor: | >0.98 |
| Power Efficiency: | >92% |
| Driver | MEANWELL, INVENTRONICS,SOSEN, according to customer needs |
| Ra | Ra>80 |
| Lumen(Lm/W) | 140lm/W |
| Control method | Ordinary, 0-10V, PMW, DALI,Photocell sensor |
| Light body material | Die-casting aluminum lamp body + pc cover +304 stainless steel screws |
| Beam angle | 60/90/60*150Deg |
| CCT: | 3000K/4000K/5000K/5700K/6500K |
| Protection level | IP66/IK09 |
| Installation diameter | Adjustable angle bracket installation |
| Lightning protection level | 10KV or 20KV, according to the actual needs of customers |
| Work temp | -35ºC~65ºC |
| Work humidity | 10%~90% |
| Warranty/Life | 5years/50,000hrs |
| Model | YSD-TGD-500W | YSD-TGD-600W | YSD-TGD-800W | YSD-TGD-1000W |
| Power | 500W | 600W | 800W | 1000W |
| Input Volt | 100-277V/277-480V/AC 50/60Hz |
| Led Type: | 5050SMD |
| Led(pcs) | 184pcs | 276pcs | 368pcs | 460pcs |
| Power Factor: | >0.98 |
| Power Efficiency: | >92% |
| Driver | MEANWELL, INVENTRONICS,SOSEN, according to customer needs |
| Ra | Ra>80 |
| Lumen(Lm/W) | 140lm/W |
| Control method | Ordinary, 0-10V, PMW, DALI,Photocell sensor |
| Light body material | Die-casting aluminum lamp body + pc cover +304 stainless steel screws |
| Beam angle | 20/40/60/90/100*140Deg |
| CCT: | 3000K/4000K/5000K/5700K/6500K |
| Protection level | IP66/IK09 |
| Installation diameter | Adjustable angle bracket installation/Adjustable module |
| Lightning protection level | 10KV or 20KV, according to the actual needs of customers |
| Work temp | -35ºC~65ºC |
| Work humidity | 10%~90% |
| Warranty/Life | 5years/50,000hrs |
