80-100kg/H Granulator Extruded Floating Fish Feed Pellet Production Line Machines Fish Food Extruder for Fish Feed

Product Description

80-100kg/h granulator extruded floating fish feed pellet production line machines fish food extruder for fish feed
Product Description
Brief Introdution:
1) Feed processing machine is also named fish feed extruder, and it is suitable for dogs, cats, fish, birds, rabbits, shrimps, dogs, cats, Mink, fox and other pet feed with different tastes. Suitable for farmers, small and medium-sized feed mills.
2) This equipment uses corn, soybean (bean cake) animal scraps as raw materials, and can be puffed directly into the machine to produce different granules with rich nutrition and fine texture.
3) The extruded feed granules produced by this machine are neat and smooth in shape, can float on the water surface for more than 12 hours without sinking, do not pollute the water source, and can be sterilized to reduce fish diseases.
4) Three motors: Main motor + feeding motor + cutting motor.
5) Working principle: Put the material into feeding device. The material will be extruded and expanded by the screw shaft with high pressure and temperature to make the material fully cooked and sterilized. Then the expanded material will be formed into different shapes through different molds.
Requirements of the raw material:
Wheat meal, maize powder, soybean meal, cottonseed meal, fish meal, bone meal, corn meal, meat meal, etc.
Moisture of raw material:20%-25%
Oil content: ≤10%
Starch content: ≥30%
Raw material type: powder
Features of Floating Fish Feed Pellet Making Machine:
* Fish feed pellet machine adopting international advanced technology, the pellets are very even.
* We can get the different size and length of pellet diameter ( diameter from 1mm to 8mm).
* The electric heating device improve the feed expansion rate.
* High temperature and high pressure can kill the salmonellosis and bacterial infections.
* Fish feed machine can get the higher-protein animal feed, and easy to digest.
Product Parameters

Model	Capacity	Size	Main Motor	Weight
SD40	30-50kg/h	1200x1100x700mm	3kw*2	280kg
SD50	60-80kg/h	1470x1100x900mm	11kw	360kg
SD60	100-150kg/h	1550x1220x900mm	15kw	430kg
SD70	180-250kg/h	1780x1500x970mm	18.5kw	650kg
SD80	300-350kg/h	1800x1550x1300mm	22kw	850kg
SD90	400-450kg/h	2300x1640xx1000mm	37kw	950kg
SD120	500-700kg/h	2560x2000x1200mm	55kw	1700kg
SD135	800-1000kg/h	2000x1700x1650mm	75kw	2300kg
SD160	1200-1500kg/h	3000x2800x1900mm	90kw	2750kg

Finished product
1. Aquatic feed pellet for fish, catfish, tilapia, tilapia fish, shrimp, crab, etc. Both floating and sinking feed pellets. The floating time can be adjusted by the different puffing degree.
2. Pet food pellet for pets like cat, dog, pet bird,
3. Other animals feed pellet, like frog, fox, rabbit, etc.
4. Poultry animals feed pellet, like chicken food, goose feed, sheep feed, etc.
A variety of mold selection, molding speed is fast: Can produce a variety of shapes, the product outlet is equipped with frequency conversion speed regulating rotary cutting device, you can arbitrarily adjust the blade rotation speed, to control the cutting speed and length
Detailed Photos
Packaging & Shipping
After Sales Service
1. Pre-sale service of fish feed extruder pellet making machine
1) Accept customer consultation, We will offer solutions according to customer requirements, determine the scale of operation;
2) To provide customers with project design, process design, suitable for your machine equipment plan formulation of choose and buy, in a timely manner to provide customers with related technical documents;According to your special requirements, design and manufacture of products, for your training technical operation personnel for preliminary design and construction design.
2. Serve for sale of fish feed extruder pellet making machine
1) The company sent technical personnel to the scene of the on-the-spot guidance equipment installation, debugging and training operators

3. After-sales service of fish feed extruder pellet making machine
1) Phone support: refers to the customers in the use of equipment of difficult problems in the process or equipment in abnormal state, by telephone or by fax to the company for technical support and help.Company after confirm the customer's service request, will arrange technical personnel within the prescribed period of time (i.e., response time) by phone to help fault locating the demand side, and put forward solutions, guide customers to exclude equipment failure in the end.
2) If you can't fault diagnosis by phone and solve the failure phenomenon, will immediately send technicians to the scene, eventually to solve.
3) The company's products provide a year warranty, life-long maintenance.
FAQ
Q1: What is the MOQ for your Fish Feed Pellet Machine?
A: Our MOQ is 1 set. And any order quantities are highly appreciated.
Q2: Payment terms ?
A: Accepted Payment Type: T/T, L/C, Western Union, Cash and so on.
After sign the contract, pay the 10%-30% deposit of total purchase price and pay the full payment before delivery.
Q3: Can you show how the machine works?
A: Certainly, we will send you the Operating video & instruction to you together with machines, to help you use the machines better.
Q4: What should i do if i want to get a best quotation?
A: Please let us know the machine capacity you need, the animal types, and your requirements.
For new price and more details, please contact us at any time. You will be satisfied with our machine quality and perfect after-sales services! Choose us and cooperate with us, we will not let you down!

---
