US$180,000.00-240,000.00
|
1 Piece
(MOQ)
|
Basic Info.
Machining Process
Hydraulic
Certification
ISO9001: 2000, CE
Min. Turning Diameter
18.4m
2ND, 3rd Axle Load
21220kg
Min. Ground Clearance
285mm
Max. Engine Torque
1862n.M
Transport Package
Nude Package
Specification
11990*2490*3900mm
Production Capacity
50pieces/Month
Product Description
China Hot Sale Truck Mounted Concrete Pump Truck Price HB37A
Products Description
• Compact in design, 38m pump mounted on a 3-axle truck.
• Efficient pump unit, ideal for long time use.
• Agile placing boom with 5 arms with unfolding height 9.61m only, which gives a wide work range.
• One side lateral support enables to work in narrow sites.
• Controller is designed for heavy duty use, with a monitor which monitors the pump intelligently on working data management, real-time diagnostics, alarm logging, and service interval notice.
• Various configurations and high quality components.
• Damping technology boom.
• Boom stabilization control.
• Multilingual machine interface system.
• PWM+CAN dual communication mode remote control.
Specifications
No.
| Item
| Unit
| Parameter
|
1
| Max. speed
| km
| 90
|
2
| Min. turning diameter
| m
| 18.4
|
3
| Brake distance
| m
| 7
|
4
| Approach angle
| °
| 31
|
5
| Departure angle
| °
| 12
|
6
| Chassis model
|
| CXZ51Q ( Japan )
|
7
| Total weight
| kg
| 28150
|
8
| 1st axle load
| kg
| 6780
|
9
| 2nd, 3rd axle load
| kg
| 21220
|
10
| Engine model
|
| 6WF1
|
11
| Max. Engine power
| kW
| 287
|
12
| Max. Engine torque
| N.m
| 1862
|
13
| Max. grade-ability
| %
| 38
|
14
| Fuel consumption limit
| L/100km
| 34
|
15
| Outline dimensions (Length´ Width ´Height)
| mm
| 11990´2490´3900
|
Technical Data for Pumping Operation
|
No.
| Item
| Unit
| Parameter
|
1
| Theoretical output
| m3/h
| 138/90
|
2
| Max. delivery pressure
| MPa
| 8.7/13
|
3
| Reach height
| m
| 37.4
|
4
| Reach depth
| m
| 23.7
|
5
| Front outrigger transverse span
| mm
| 7280
|
6
| Rear outrigger transverse span
| mm
| 6600
|
Prouct Images
Our Advantages
>>
