| CPU | Intel® 6/7/8/9/10th Generation Core™ i3/i5/i7, Pentium®, Celeron® CPU, FCLGA1151 |
| Chipset | Intel® Q270/C422, TDP 6W |
| Display | 1*HDMI+1*VGA(onboard interface) |
| RAM | 2*DDR4 LO-DIMM, Max.128GB |
| Ethernet | 6*Intel I226V 2.5Gbe RJ45+2*82599 10Gbe SFP+，supports WOL/PXE; 2*PCIe x8 expansion，2 segment Bypass(optional) |
| Bypass | 2x segment, LAN1/2 & 3/4 |
| Storage | 1*SATA3.0+1*SAS(4*SATA)+1*M.2 NVME/SATA |
| Expansion | 1*M.2, supports 4G/5G module + 1*SIM card slot |
| 1*M.2, supports WIFI6 module | |
| Front I/O | 1*Power ON/Reset |
| 1*PWR/HDD LED Light | |
| 1*Console(Cisco standard) | |
| 1*USB3.0 | |
| 1*HDMI | |
| 1*RJ45(1X6) | |
| 2*SFP | |
| Inner I/O Interface | 1*HDMI,1*VGA_H |
| 1*GPIO,16bit; 1*TPM2.0 interface | |
| 1*AUTO_ON,1*CLR_CMOS,1*J bypass | |
| 1*LAN_LED | |
| 1*F_Panel,1*PS/2 | |
| 2*F_USB2.0+1*USB2.0 | |
| BIOS | AMI UEFI 256M |
| Watchdog | 0~255，programmable. Timeout interrupt or system reset |
| Power Supply | 4PIN(12VDC) + 24PIN ATX，supports S0、S4、S5；Supports AC power-on auto boot function |
| OS | windows10/11/Linux/RTOS/Ubantu/FreeBSD/CentOS etc. |
| HeatSink | 1*CPU_FAN ,2*SYS_FAN, supports 4Pin smart fan |
| OTM | -10℃～60℃ |
| STM | -20℃～70℃ |
| Humidity | （40）℃ （95）%RH non-condensing |
| Dimension | 288*207mm |
