Vtm5912 Table Movable Type Vertical Turning Lathe/ Customerized Machine

US$300,000.00-2,000,000.00 1 Piece (MOQ)

Basic Info.

Type
Vertical Lathe
Processing Accessory
Centre CNC Lathe
Guide Rail
Horizontal Guide Rail
Tool Holder
Double-tool Holder CNC Lathe
Power Source
Hydraulic Pressure
Controlling Mode
CNC
Automatic Grade
Semiautomatic
Setting Mode
Table
Precision
High Precision
Certification
ISO 9001
Condition
New
Working Condition
No Dust, No Harmful Gas/Liquid.
Temperature
5-40
Relative Moisture
Less Than 85%
Power Supply
415V/380 50Hz
Transport Package
Wood
Specification
iron
Trademark
WZ
Origin
China
HS Code
8457101000
Production Capacity
50

Product Description

APPLICATION
VTM59 series turning and milling combined machine can complete turning, milling, drilling, boring and tapping by once set up. X/Y/Z/C 4 axis linked machining can be realized.
The machine is especially suitable for turning, milling, drilling, boring and tapping by once set up of small sized precision and complicated part.
The main performance characteristics: Table can travel back-force, with CNC Y axis. X/Y/Z/C can realize 4-axis linked machining. Table adopts high accuracy double row roiler bearing in radial for centering; in axial adopts large sized ball thrust bearing for supporting. Table can adopt double AC spindle motor drive; can realize high precision electric gap elimination. Toolhead ram travel adopts ballscrew pair transmission; guide way adopts pump per pocket closed type hydrostatic guide way of constant flow. Milling spindle is housed in toolhead; AC spindle motor drive; 2-shift gearbox speed change.
Main technical parameters:
Item Unit Model
VTM5912 VTM5916 VTM5925
Max turning job diameter mm Φ1250 Φ1600 Φ2500
Max tuming job height mm 1000 1200/1500 1500/2000
Table diameter mm Φ1050 Φl400 Φ2000
Table max loading capacity r/min 5 8 16
Table turning max speed r/min 300 250 200
Table max torque kN.m 10 20 40
Ram section size mm2 280 280 280
Ram max travel mm 1000 1000/1400 1400
Milling spindle power kW 31 31 31
Milling spindle max torque N.m 750/1000 750/1000 750/1000
Milling spindle highest speed r/min 3000 3000 3000

Detailed Photos
Workshop
Package
Installation and commissioning
