Concrete Dry Batching Plant Asphalt Batch Mixing Plant Parts

Product Description

Product Description

Model		HZS60	HZS90	HZS120	HZS180	HZS240	HZS270
Productivity		60	90	120	180	240	270
Mixer	Model	JS1000	JS1500	JS2000	JS3000	JS4000	JS4500
	Power	2*18	2*30	2*37	2*55	2*75	2*75
	Discharge capacity	1000	1500	2000	3000	4000	4500
	Aggregate maximum size	≤60/80	≤60/80	≤60/80	≤60/80	≤60/80	≤60/80
Batching chamber		3*12	3*12	4*20	4*20	4*25	4*25
Weighing range and accuracy	Aggregate	3*(1000±2%)%	3*(1500±2%)%	3*(2000±2%)%	3*(3000±2%)%	3*(4000±2%)%	3*(4500±2%)%
	Cement	500±1%	800±1%	1000±1%	1500±1%	2000±1%	2500±1%
	Coal ash	150±1%	200±1%	400±1%	600±1%	800±1%	900±1%
	Water	150±1%	200±1%	400±1%	600±1%	800±1%	900±1%
	Additive	20±1%	30±1%	40±1%	60±1%	80±1%	90±1%
Discharge height		4.2	4.2	4.2	4.2	4.2	4.2
Overall power		100	150	200	250	300	300

Company profile
Tai'an Chenli Construction Machinery Co., Ltd. is a technology-based company focusing on the development, design, manufacturing, engineering and service of intelligent complete equipment for building materials. Based on a deep understanding of building intelligent equipment, Taian Chenli is committed to providing users with "practical, efficient, low-carbon, environmentally friendly, intelligent and advanced" intelligent equipment products. In line with the product concept of "excellence in quality, simplicity to the extreme", committed to the high-tech development and application of intelligent equipment, energy-saving and environmentally friendly equipment for new building materials. The current leading products are cement concrete batching plants, mortar production lines, tower type sand making machine, and environmental protection equipment for batching plants. The products win the trust of the market with high standards and high reliability, and are deeply trusted by users.

---
