o Electrical Specifications
|
Item
| Specifications
|
Frequency Range(MHz)
| 8^10
| 10^24
| 24^104
|
Mode
| AT/Fundamental
|
Load Capacitance (CL)
| 8pF,9pB 10pB 12pB 18pB20pB or Specify
|
Frequency Tolerance( at25°C)
| ±10ppm ~ ±30ppm or specify
|
Operating Temperature Range
| -20~+70°C or Specify
|
Frequency Stability Over Operating Temperature Range
| ±10ppm ~ ±30ppm or specify
|
Equivalent Series Resistance (ESR) max.
| 200Ω
| 80Ω
| 60Ω
|
Storage Temperature Range
| -55~+125°C
|
Shunt Capacitance! C 0)
| 3pF Max
|
Drive Level (Typical)
| 1-100 pW (50pW typical)
|
Aging @25°C 1st Year (Max)
| ±3 ppm/year max
|
