Stainless Steel High Shear Mixing Tank Emulsification Tank

US$2,800.00-8,300.00 1 Piece (MOQ)

Basic Info.

Model NO.
WYES-800
Application Area
Food
Certification
CE
Condition
New
Main Material
Stainless Steel
Mixing Drum Shape
Disc
Stirring Type
Spiral
Working
High Speed Mixer
Capacity
800L
Material
SUS304
Heating Mode
Steam Heating
Number of Layer
Two Layers
Motor Power
3kw
Mixing Speed
3500rpm/ 1750rpm
Motor Position
Top or Bottom
Mixer Type
Agitator
Layout Type
Verticle
Operating type
Cycle Operating
Transport Package
Wooden Case
Origin
Wenzhou China

Product Description

Emulsifying tank stainless steel high shear mixing tank
Here is the high shear mixer, or you can call it high shear mixer, mixing speed is 3000rpm.
Made into 3 layers or 2 layers, inner layer was the contact part with your raw material such as milk, juice or any other liquid product… Outside the inner layer, there is a heating / cooling jacket for steam or hot water / cooling water. Then comes the outer shell. Between outer shell and the jacket, there is a 50mm thickness temperature preservation layer.
Emulsifying tank pictures:
----Motor at the bottom
The specification of emulsifying tank
Model LRG-1T LRG-2T
Capacity 1000Liter 2000Liter
Construction material AISI304 AISI304
Design pressure 0.3Mpa 0.2Mpa
Working pressure 0.25Mpa 0.25Mpa
Design temperature 171 degree C 171 degree C
Working temperature 110 degree C 110 degree C
Heating medium Steam / hot water Steam / hot water
Cooling medium Tap water / ice water Tap water / ice water
Mixing speed 3000rpm / 960rpm 3000rpm / 1450rpm
Mixer type high shear mixer / disperser high shear mixer / disperser
Motor power 3kw 5.5kw
Dimension Φ 1300 ×2100mm Φ 1500 ×2300mm
