Pet Foam Core Production Line Twin-Screw Extruder Machine

Product Description

Feininger PET foam core production line is a special equipment that combines reactive extrusion and foaming processes. It is one of the best PET extrusion lines in China.
Because of our special extruders, the quality of our PET foam core machine has high performance, low energy consumption, durability and versatility. Therefore, our machine has been widely used in more than ten countries and regions in the world.
Specification

Model	Raw Materials	Additives	Foam Agent	Output	Density	PET Foam Board Width	PET Foam Board Thickness
FS95T/250C	PET (Bottle grade polyester chips)	chain extender, nucleating agent, ...	CO2, Cyclopentane	400kg/hr - 650kg/hr	60kg/m3 - 120kg/m3	1000-1250mm	5-60mm

Our Advantages
CO2 Foaming
Traditional foam agent used in the PET foam core production line is fluoride, which has an impact on the environment and human health. However, our PET extrusion line can use composite foaming agent "CO2" to replace "fluorine series" foaming agent, which not only will greatly reduce the production cost but also can achieve zero emissions of greenhouse gases.
High performance-cost ratio
After one year's experiment, Feininger company has realized the full localization from material processing, screw structure of main extruder, pressure temperature control, mold forming to post-processing adhesion, thus greatly reducing the manufacturing cost of equipment, and on the premise of ensuring quality, its cost is far lower than similar foreign equipment.
Advanced technology
Perfectly realized the equipment structure of double-section machine for product production, and the capacity is increased on the basis of ensuring the product production process.
After-sales guarantee
As the R&D company and manufacturer of PET foaming board production line, Feininger company can provide comprehensive product production process training and continuous technical guidance for customers.
Composition

1	Automatic Loading system with 5 feeding units
2	Primary Extruder:(twin screws)
3	Blowing Agent Injection System
4	Hydraulic Screen Exchanger with Hydraulic pressure station
5	Secondary Extruder:(single screw)
6	Static Mixer
7	DIE UNITS
8	Haul-off Unit
9	Cooling Racks
10	Second haul-off
11	Online planing machine(optional)
12	Widthwise Cross Cutting System
13	Driving Rollers
14	Revolving Cooling Unit
15	CENTRAL CONTROL STATION

Factory Requirements
1, Power Supply: 800KVA, 3 phases, 380V, 50HZ
2, Normal running power: 300KW-400KW
3, Compressed Gas: 7bar, >=6m3/min
4, Cooling Water: 4bar, 80m3/hr,15ºC (recommend to use industrial chiller)
5, Floor space:Min. L*W*H, 120M*25M*10M (this is the basic requirement)
6, Foundation: firm base ≥15cm reinforced cement (recommended)
After receiving the down payment, Feininger will provide the loads and forces for the foundation requirement for the extruders, revolving cooling unit and central dust collection system. 7, Labor required: 1-3 skilled workers /shift (3 shifts/day recommended )
8, Ambient condition: Forced draught, vented, laminated , ambient temperature should be above 0 ºC, Bottom of workshop need ventilation, Ventilation Device must be installed on the Die port and Screen Changer by Customer.
9, Fire-fighting Grade: Plant design should reach safety requirements for that of Electronic products, Fire Extinguishing is requested around the production line. Check the details refer to the annex file.
Application of PET Foam Core
Company Profile
Feininger takes "Basing On Talents, Leading the Technology" as its policy and focus on faithful business, which has enabled us to grow rapidly in Feininger takes "Basing On Talents, Leading the Technology" as its policy and focus on faithful business, which has enabled us to grow rapidly inface of the fierce competitions. Our products were sold to Australia, America, Middle east Asia, Europe and wins good customer feedback.
With the continuous improvement of performance level, Feininger's experience and continuous research on technology and solutions, plastic material extruders improve the productivity of the production line, reducing costs and energy consumption.
Feininger successfully won certificates of ISO9001:2008, ISO14001:2004 and CE, which ensures stable quality control. In addition, we accentuate humanization design with goal to offer quality and humanized products. Strict quality control is our promise to customers. Before products are delivered, each lot is inspected severely.

---
