All-in-One 5kw/10kw/15kw/20kw Hybrid Home Solar Panel Power/Energy Storage System with Inverter&Battery

Product Description

Product Description
Factory For Solar PV Panel off Grid Energy Power System
0.5KW-30KW Hybrid Solar Energy System
5kw 10kw 15kw 20kw 25kw 30kw Complete Solar Cells Photovoltaic PV Panel Products Inverter Generator Kits Supply Solar Energy Storage Home Power System
off-Grid Generator Home Install 20kw Hybrid Photovoltaic Solar Panel Power Energy System
What is Hybrid Solar Energy System?Hybrid Solar Energy System Also Named On&Off Grid Solar Energy System. With the feature and function of both on grid and off grid solar energy system. If you have a set of hybrid solar energy system, you could use electricity from solar panel in the daytime when is sunny, you could use electricity stored in battery bank in the evening or on rainy days.
The grid-tied solar system is an electricity generating solar PV power system that is connected to the utility(State) grid. It consists of solar panels, one or several on grid inverters, Wifi Monitor Device, Mounting Brackets and grid connection equipments.Users can feed excess power to the grid where it is consumed by other users. The feedback is done through a meter to monitor power transferred to AC loads single phase(110/120V;220/230/240Vac) or three phase(240V;380V;480Vac). If photovoltaic wattage substantially exceeds average consumption, the energy produced by the panels will be much in excess of the demand. In this case, the excess power can yield revenue by selling it to the grid with local feedback policy.
Product Parameters
Technology Advantage

4.4kwp+5.5kw+10kwh off-grid system
Project	Serial number	Project Details	unit	quantity	Remark
Photovoltaic system	1	Photovoltaic module 550W/41.6V	piece	8	8 strings Operating voltage: 41.6V Weight: 26.5KG Size: 2279*1134*35mm
	2	Bracket	set	1	custom
	3	MC4 plug	right	10	custom
	4	Single core cable PV1-F 1×6.0	meter	200	From module to wall-mounted hybrid inverter, 100 meters for red and black
Control-inverter system	5	Wall-mounted hybrid inverter GST48-5.5KW	set	1	AC220V/50HZ, full load 5500W, MPPT voltage range 70-450Vdc
Lithium battery	6	Wall-mounted lithium iron phosphate battery GBP48-200W	set	1	10KWh,including battery cable and communication cable
5.5kwp+5.5kw+20kwh off-grid system
Project	Serial number	Project Details	unit	quantity	Remark
Photovoltaic system	1	Photovoltaic module 550W/41.6V	piece	10	2 strings and 2 pairs Operating voltage: 41.6V Weight: 26.5KG Size: 2279*1134*35mm
	2	Bracket	set	1	custom
	3	MC4 plug	right	12	custom
	4	Single core cable PV1-F 1×6.0	meter	200	From module to PV bus box, 100 meters for red and black
Control-inverter system	5	Wall-mounted hybrid inverter GST48-5.5KW	set	1	AC220V/50HZ, full load 10000W, MPPT voltage range 70-450Vdc
	6	PV bus box GSB3A	set	1	3 in 1 out, rated voltage 500V
	7	BVR16mm²	meter	30	From the PV bus box to the wall-mounted hybrid inverter,15 meters for red and black
Lithium battery	8	Wall-mounted lithium iron phosphate battery GBP48-200W	set	2	2 sets in parallel (20KWh),including battery cable and communication cable

The solar power system consists of photovoltaic modules (including brackets), photovoltaic combiners, solar controllers, batteries (including battery cabinets),and inverter.

Detailed Photos

---
