| US$15,500.00-27,800.00 | 1 Set (MOQ) |
| 1 | Machining Hole Diameter | Ø12-Ø200mm |
| 2 | Allowable load of table | 200kg |
| 3 | Maximum stroke Depth | 600mm |
| 4 | Spindle motor power | 1.5KW |
| 5 | Spindle reducer ratio | 3:01 |
| 6 | Spindle Speed range | 100-1000rpm(CVT) |
| 7 | Return Oil Pump flow | 100L/min |
| 8 | Stroke Motor | 2.2KW |
| 9 | Stroke Control Type | "Servo Motor+Ball Screw" |
| 10 | Stroke Speed | 0-40m/min(CVT) |
| 11 | Honing tool Qty | 1 Axis |
| 12 | Single Working Station | 1(Single Honing tool) |
| 13 | Feeding Torque | ≥20NM |
| 14 | Honing Accuracy | ≤0.1mm |
| 15 | Feeding Type | Constant feed |
| 16 | Machine Weight | About 2.5 Tons |
| 17 | Machine Size L×W×H | 1500×1500×2700mm |
| 18 | Noise standard | Less 80 dB Normally |
