Horizontal Bandsaw Timber Wood Portable Sawmill

Product Description

Product Parameters
Portable Electric Sawmill Horizontal Band Saw Wood Cutting Bandsaw Machine
Popular and highly trusted in
Africa:
Angola,Cameroon,Ethiopia,Egypt,IvoryCoast,Gambia,Ghana,Kenya,Mauritius,Mozambique,Namibia,Sierra Leone,South Africa,Tanzania,Uganda,Zambia,Zimbabwe
Asia:
Bahrain,Bhutan,Burma,India,Indonesia,Israel,Malaysia,Philippine,Sri Lanka,South Korea,Singapore,
Thailand,Uzbekistan,Vietnam.
Europea:
Bulgaria,Bosinia and Herzegovina,Belarus,Finland,France,Holland,Hungary,Italy,Greece,Spain,
Sweden,Turkey,UK,
Oceania :
Australia,Fiji,New Zealand,Papua New Guinea,
America :
Brazil,Canada,Nicaragua,Peru,Panama,USA

Model	WS700E	WS1000E	WS1300E	WS1600E
Max. Sawing Wood Width	700MM	1000MM	1300MM	1600MM
Saw Wheel Diameter	700MM	700MM	700MM	700MM
Sawing Wood Thickness	2-300MM	2-300MM	2-300MM	2-300MM
Sawing Wood Length	1300-4500MM (Rail Length:5800MM)
Main Motor Power	15KW	18.5KW	22KW	30KW
Up/Down Sizing	1.5KW	1.5KW	1.5KW	1.5KW
Total Weight (KG)	900	1100	1300	1500

Diesel Portable Sawmill Horizontal Band Saw Wood Cutting Bandsaw Machine

Model	700D	1000D	1300D	1600D
Max Sawing Width	700MM	1000MM	1300MM	1600MM
Saw Wheel Diameter	700MM	700MM	700MM	700MM
Sawing Thickness	10-300MM	10-300MM	10-300MM	10-300MM
Diesel Engine	22HP	22HP	25HP	27HP
Saw Blade Length	5500MM	6100MM	6600MM	7100MM
Total Weight (KG)	1100	1200	1300	1500
Manual Forward/backward,Hydraulic Up/down for setting sawing thickness.

Related Machines
Mini Portable Sawmill

Model	23	26	31	36
Max sawing Width	580MM	660MM	780MM	900MM
Max Sawing Length	3000MM	3000MM	3000MM	3000MM
Saw Wheel	410MM	480MM	480MM	580MM
Petrol/Diesel /Electric	8HP/7.5KW	8HP/7.5KW	15HP/7.5KW	15HP/11KW
Saw Blade	3660*35	3750*35	4070*35	4100*35

Hydraulic Portable Electric Sawmill
Model	700A		1000A	1300A
Max Sawing Wood Width	700MM		1000MM	1300MM
Saw Wheel Diameter	700mm		700mm	700mm
Max Sawing Wood Thickness	300mm		300mm	300mm
Standard Sawing Wood Length	4500mm		4500mm	4500mm
Electric Motor Power	22kw		30kw	30kw
Up/Down Motor	1.5KW		1.5KW	1.5KW
Forward/Backward Motor	2.2KW		2.2KW	2.2KW
Saw Blade Width	27-75MM		27-75MM	27-75MM

Hydraulic Portable Diesel Sawmill
Model	1000D		1300G
Max Sawing Wood Width	1000mm		1300mm
Saw Wheel Diameter	700mm		700mm
Max Sawing Wood Thickness	300mm		300mm
Standard Sawing Wood Length	4000mm		4000mm
Engine Power	22HP Diesel Double Cylinder		35HP Petrol Double Cylinder
Up/Down	Hydraulic		Hydraulic
Saw Blade Thickness	27-75mm		27-75mm
Machine Length	5800mm		5800mm
Weight	2500kg		2500kg

Heavy Duty Horizontal Band Saw Mill Machine
Model	1200	1500	2000	2500
Max Sawing Width (MM)	1200	1500	2000	2500
Saw Wheel Diameter (MM)	1000	1000	1070	1070
Max Sawing Thickness (MM)	450	450	450	450
Band Saw Blade Length (MM)	7700	8600	9300	10500
Max Sawing Length (Meters)	6	6	6	6
Saw Wheel Motor (KW)	30	37	45	55
Touch Screen Up/Down Sizing Motor(KW)	2.2	2.2	2.2	2.2
Forward/Backward Motor (KW)	3	3	3	3
Blade Tension Motor (KW)	1.5	1.5	1.5	1.5

Company Profile
Specialize in research & development, production, sales of sawmills and the relevant fittings SINCE 1988
We have serves 11,000 enterprises and our products have been exported to over 60 countries in the world.
Our wood band Sawmill including:
Hydraulic Heavy Duty Horizontal Sawmill
Hydraulic Portable Horizontal Sawmill
Multiple Heads Horizontal Resaw Band Saws
Heavy Duty Horizontal Sawmill
Portable Horizontal Sawmill
Thin Cutting Horizontal Resaw
Mini Portable Sawmill
Twin Vertical Band Sawmill
Vertical Band Sawmill
Log Carriage (Manual,Electric,Pneumatic,Hydraulic)
Band Saw Blade
Band Saw Blade (Sharpener,Butt Welder,Roller)
Brazing Machine (Manual/Automatic Stellite/Tungsten)
Blade Grinding Machine(Manual/Automatic ,Side/Angle)
Sawmill & Kilns & Pallet & Biomass & Forestry & Recycling
