| US$230.00-870.00 | 1 Piece (MOQ) |
| Specification | TVR-10KVA | TVR-15KVA | TVR-20KVA | TVR-30KVA | TVR-45KVA | TVR-60KVA | |
| Input | Phase | Three phase | |||||
| Voltage | Phase voltage 176V-256V,Line voltage304V-456V | ||||||
| Frequency | 50Hz / 60Hz | ||||||
| Output | Voltage accuracy | Phase voltage220V±2%,Line voltage380V±2% | |||||
| Frequency | 50Hz / 60Hz | ||||||
| Protection | Low Volt. | 318V±7V | |||||
| Over Volt. | 426V±7V | ||||||
| ByPass | Yes (AUTO/MANUAL OPTIONAL) | ||||||
| Protective function | With overvoltage, undervoltage, overcurrent, short circuit, phase sequence protection and other functions; | ||||||
| Efficiency | AC-AC | >90% | |||||
| Noise | Noise Level | ≤50dB | |||||
| Environmental | Temperature | -5ºC~45ºC Degree | |||||
| Humidity | 15% to 90% | ||||||
| Parameter Information | Load work | 80% continuous load | |||||
| Protection degree | standard IP21(outdoor Customizable IP rating) | ||||||
| Type of cooling | Fan cooling | ||||||
| Total harmonic distortion | No additional waveform distortion | ||||||
| Insulation class | Class B | ||||||
| Insulation withstand voltage | 2500VAC/min(No breakdown) | ||||||
| Altitude | <1500M | ||||||
| Output type | Unified output adjustment, output adjustment for each phase | ||||||
| Self-starting function | When the power fails and then resumes, it will automatically start, no need to manually | ||||||
| Responds Time to voltage variation | The response time is 10 ms, and the adjustment speed is 15V/s | ||||||
| Accessories | Random accessories: 1 voltage stabilizer main board, 1 voltage stabilizer display screen, 2 cooling fans, 2 intermediate relays, 1 power supply transformer, | ||||||
| Install | No severe vibration or turbulence; no gas, vapor, chemically deposited dust, dirt and other explosive and corrosive media that seriously affect the insulation of the voltage stabilizer; | ||||||
| Packaging | Shipping Wt.(KG) | 90KG | 102KG | 113KG | 130KG | 155KG | 160KG |
| Dimensions (D*W*H mm) | 580*320*530mm | 580*320*530mm | 680*360*580mm | 680*360*580mm | 640*400*880mm | 640*400*880mm | |
| Why us? | |
| Reasons you would prefer to buy this power supply products from us | |
| Service | RMA(24/7 pre-sales and after-sales support),OEM,ODM |
| Quality | Highly reliable quality guaranteed by Varta production equipment, German technology, European raw materials |
| Warranty | Standard 2 years, 5+ years upon request |
| Price | Competitive factory Price! Cut down the cost you paid to the middle man |
| Professional | Founded in 1985, 30+ years battery manufacturing experience |
| Production capacity | 3,500,000KVAh per year |
| Reliable | Two R&D centers; Three major production bases; Global 500+ dealers/ agents; Global 100+ offices; Business coverage 65+ countries around the world |
| Shipping & Payment | |
| Payment | T/T, L/C , Cash, Western Union etc.(flexible payment term can be discussed) |
| Port | Normally Shenzhen China (any sea port upon request) |
| Delivery | By sea/air/trian/truck transportation |
| Delivery time | Normally 4 weeks ex factory excluding shipping. |
| Packing: | Pack in carton box then pallet (wooden box) |
