Application
Printing machine could be used for printing materials as following:
1.Polyethylene, polyethylene plastic film.
2.Bag(packing bag for food, supermarket handbag, vest bag and clothes bag),
3.Roller paper and craft paper
4.Pp woven bag , pvc film, bopp film,
5.Laminated bag ,
6.Non woven bag,
7.Rice bag
8.Paper cup etc
Model
| BSYT-2800
| BSYT-4800
| BSYT-6800
|
Max. Material Roller
| 1200mm
| 1200mm
| 1200mm
|
Max. Material Width
| 800mm
| 800mm
| 800mm
|
Max. Printing Width
| 780mm
| 780mm
| 780mm
|
Printing Length
| 200-1200mm,or customied
|
Print Colors
| 2 colors
| 4 colors
| 6 colors
|
Mechanical Speed
| 80m/min
| 80m/min
| 80m/min
|
Printing Speed
| 5-60m/min
| 5-60m/min
| 5-60m/min
|
Total Power
| 10kw
| 12kw
| 15kw
|
Plate Thickness (including two-sided glue paper)
| 2.38mm, or customied
|
Machine Weight (kg)
| 2500kg
| 3500
| 4500
|
Overall Dimension (m)
| 4x1.8x2.2
| 6x1.8x2.4
| 6x1.8x2.4
|
Working Voltage
| 380V 3-phase 50Hz, or customied
|
Main Features
1. Easy operation, flexible starting, accurate Ppcolor register.
2. The meter counter can set printing quantity according to the requirements. Stop the machine automatically at the quantity or when the material is cut off.
3. Printing cylinder lift and lower, it will stir the printing ink automatically after lifting.
4. The printing ink is spread by the anilox cylinder with even ink color.
5. Reliable drying system coordinated with high-speed rotation, it will automatically break circuit when the machine stops.
6.360°continuous and adjustable longitudinal register device.
7. The motor has inverter controller with different speed.
8. The electric board with buttons let machine operation be easy and effective.
9. Automatic laoding material, computer control is available.
Extra Optional Devices:
1) EPC web guider + Auto tension controller
2) Digital Corona Treater
3) Air Shaft
4) Computer control system for colour register
5) High speed
6) High exported brands parts
7)Ceramic anilox roller
8) Automatic material laoder
Other types for your reference.
BAG PRINTING MACHINE
Printing bag one by one
1, 2, 3, 4 colors for you choice.
High speed
Automatic controller system
pp woven bag
non woven bag
paper bag
2 COLORS PRINTING MACHINE
Economic type roller to roller
Winder rolling diameter Dia 600mm to 1000mm
Rewiner Dia 450-600mm
Manual or auto tension controller
Web guide photo for auto web deviation
Inverter control
PP woven printing
Film printing
Non woven roller printing
4 COLORS PRINTING MACHINE
Winder could be manual or automatic tension contoller
Rewinder be tension controller or torque motor
Web guide automatic correction.
Automatic tension controller
Computer regisiter option
Blades option
Corona treatment option
Air shafts or steel roller
8 COLOR PRINTING MACHINE
Automatic material laoder winder unit option
Rewinder could be tension controller or torque motor
Web guide automatic correction.
Automatic tension controller
Computer regisiter option
Blades options
Singe rewinder or double rewinder options
Speed could be middle speed.high speed option
Detailed Images
Sample Photo
2 colors print machine for printing non woven roller, plastic film, craft paper see following:
4 colors Automatic type for printing non woven, plastic film, rice bag, woven bag, paper material see following:
Control system Print unit Photo web guide 4 colors
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* View our Factory.
After-Sales Service
* Training how to instal the machine, training how to use the machine.
* Engineers available to service machinery overseas.
